6AV7884-2AH30-4BW0 SIMTAIC IPC 477 15" Touch Screen
Categories | SIMATIC IPC 477 |
---|---|
Brand | VICPAS |
Model | 6AV7884-2AH30-4BW0 |
Brand | Siemens |
Warranty | 365 Days |
Product Line | IPC 477 |
Supply | IPC 477 Touchscreen and Overlay |
Size | 15 inch |
Terms of Payment | Western Union, T/T, PayPal, Credit Card |
Update Time | Oct 9,2024 |
6AV7884-2AH20-4BP0 Siemens SIMATIC HMI IPC 477 Touch Screen Panel, Overlay, Front Cover and LCD Display Repair Replacement
SIMATIC HMI IPC477C, 15" Touch display, 1024x 768, Standard front w. USB interface Intel Core 2 Duo 1.2 GHz, 4 GB SD-RAM (DDR3), 2x Ethernet 1 Gbit/s; 1x PROFIBUS DP12; 4xUSB 2.0, 500 mA, 1x RS232 (COM1), Power supply 24 V DC, 1x free CF slot, 8 GB CF card, Windows Embedded Standard 2009 WinCC V7.0 Runtime pre-inst., WinCC license 2048PT
package for your device.
The SIMATIC IPC477E is available in the following device variants, which differ in regard tothe display size, operating method and optional expansions:Devices with resistive single touch screen● Display:
– 15'' display, resolution: 1280 x 800 pixels
– 19'' display, resolution: 1366 x 768 pixels
– 22'' display, resolution: 1920 x 1080 pixels
● with PCIe slot
VICPAS supply 6AV7884-2AH20-4BP0 Siemens IPC 477 touch panel, Overlay and LCD display. All of them with VICPAS 365 days warranty and support Urgent Worldwide Shipping.
Specifications:
The table below describes the parameters of the 6AV7884-2AH20-4BP0 Siemens IPC 477 Spare Parts.
Part Number : | 6AV7884-2AH20-4BP0 |
Size | 15 inch; |
Display | TFT |
Warranty: | 365 days Warranty |
Product Line: | Siemens IPC 477 |
Resolution: | 1280 x 800; |
Number of colors: | 256 |
Control elements: | Touch screen |
MTBF: | 30 000 h |
PLC Connection: | SIMATIC S7-200 |
Siemens IPC 477 HMI Manuals PDF Download:
FAQ:
Question:What are the procedure to switch on the IPC477C Touch Panel?
Answer:1. Set the on/off switch to the "ON" position.
The module carries out a self-test. During the self-test, the following message appears:Press ESC for boot options
2. Wait for the message to disappear.
3. Follow the instructions on the screen.
4. Make the region and language settings.
If you want your system language to be international, select English. Information aboutchanging the region and language settings subsequently can be found in the section"Installing the software" under "Maintaining and servicing your device".
5. Type in the product key as required.
The product key is located on the "Certificate of Authentication", in the "Product Key" line.
Question: What is the dimension of the Siemens IPC 477 Touchscrenn?
Answer:The touchscreen of 6AV7884-2AH20-4BP0 SIMATIC IPC 477 is 15 inch
Question: What is the 6AV7884-2AH20-4BP0 Siemens IPC 477 HMI parts price?
Answer: Submit a fast quote, send VICPAS an email for best price.
Common misspellings:
6V7884-2AH30-4BW06A7884-2AH30-4BW0
6AV884-2AH30-4BW0
6AV784-2AH30-4BW0
