81-0121 3NET750-1050-01 Membrane Keyboard Keypad

81-0121 3NET750-1050-01 Membrane Keyboard Keypad

81-0121 3NET750-1050-01 Membrane Keyboard Keypad
CategoriesMembrane keypad for other operator panel
BrandVICPAS
ModelTP3937S1 DMC107437Q3J25D04
TypesResistance touch screen
Touch pointsSingle-touch
Warranty365 Days
Shipping2-3 workdays
Name81-0121 3NET750-1050-01 Membrane Keyboard Keypad
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, MoneyGram, T/T, Paypal, PayPal, Credit Card
Download DOCpdf icondoc iconrar icon
Update TimeMar 28,2024
Detail Information
81-0121 3NET750-1050-01 Membrane Keyboard Keypad Repair

 81-0121 3NET750-1050-01 Membrane Keyboard Keypad Repair

81-0121 3NET750-1050-01 Membrane Keypad Material: Polyester or Polycarbonate. 81-0121 3NET750-1050-01 Membrane Keyboard Artwork Format: CorelDraw, Adobe Illustrator AI or EPS, AutoCAD Dwg or DXF. 81-0121 3NET750-1050-01 Operator Panel Keypad Tactile Feel: Is determined by the thickness of the overlayer. Normally between 0.06” -0.08". 81-0121 3NET750-1050-01 Operator Keyboard Conductive Trace: Silver or Copper. 81-0121 3NET750-1050-01 Membrane Switch Dome: Stainless Steel or Mylar. 81-0121 3NET750-1050-01 Touch Screen Keypad Life Cycle: 5 Million Cycles(up to).

 Contact VICPAS for Product Dimension


Product Feature:


Size :   inch;
Shipping : 2~3 Workdays
Warranty : 365 Days

Electrostatic Endurance No abnormal appearance after 10kv, 100Ω , 250PF electrostatic used
Isolation Resistance >20MΩ @ DC 25V
Resistance 300Ω < X Axis <900Ω , 200Ω < Y Axis <800Ω (Varies with different size)
* Performance
Linearity Error <1.5%
Response Speed <10ms
* Mechanical
Input Method Finger or gloved hand (rubber, cloth or leather)
Touch Times More than 1 million touches
Touch Activation Force 20~80g
