6ES7634-1DF02-0AE3 SIMATIC Siemens C7 634 Membrane Switch

6ES7634-1DF02-0AE3 SIMATIC Siemens C7 634 Membrane Switch

6ES7634-1DF02-0AE3 SIMATIC Siemens C7 634 Membrane Switch
6ES7634-1DF02-0AE3 SIMATIC Siemens C7 634 Membrane Switch6ES7634-1DF02-0AE3 SIMATIC Siemens C7 634 Membrane Switch6ES7634-1DF02-0AE3 SIMATIC Siemens C7 634 Membrane Switch6ES7634-1DF02-0AE3 SIMATIC Siemens C7 634 Membrane Switch6ES7634-1DF02-0AE3 SIMATIC Siemens C7 634 Membrane Switch
CategoriesSimatic C7 Series
BrandVICPAS
Model6ES7634-1DF02-0AE3
BrandSiemens
Warranty6 Months
Product LineSiemens C7 series
width230mm
height193.5mm
SupplySiemens C7-634 membrane keyboard HMI Case
model6ES7634-1DF02-0AE3
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, MoneyGram, T/T, Paypal, PayPal, T/T ,Credit Card, Western Union
Download DOCpdf icon
Update TimeMar 28,2024
Detail Information

6ES7634-1DF02-0AE3 Siemens SIMATIC HMI C7-634 Membrane Keyboard, Plastic Cover Body, Mounting Clips, Gasket and Power Supply Connector Repair Replacement

Order each part separately is available

6ES7634-1DF02-0AE3 Siemens SIMATIC HMI C7-634 Membrane Keyboard, Plastic Cover, Mounting Clips, Gasket and Power Supply Connector Repair Replacement

6ES7634-1DF02-0AE3 SIMATIC C7-634/P, COMPACT UNIT WITH INTEGRATED COMPONENTS: S7-300 CPU 315, OP17, IM 360 16DI, 16DO, 4AI, 4AO, 4 UI

The C7 devices are available in the following variants:
• C7-634 P, C7-634-DP

The C7-634 P and C7-634 DP control systems have a SIMATIC S7-300CPU 315 or CPU 315-2 DP as the C7 CPU and an OP 17 as the C7 OP.


The SIMATIC 6ES7634-1DF02-0AE3 screen display can be configured as follows:
• Four lines of 20 characters with 11 mm character height or
• Eight lines of 40 characters with 6 mm character height.

The C7-633 DP and C7-634 DP control systems can be connected via theintegrated DP interface to a PROFIBUS DP network.

VICPAS supply 6ES7634-1DF02-0AE3 Siemens C7 634 membrane switch, Housing, Gasket, Mounting Clips and Power Supply Connector with 6 months warranty and support Urgent Worldwide Shipping.





Specifications:

The table below describes the parameters of the 6ES7634-1DF02-0AE3 Siemens c7-634 HMI Parts.

Part Number : 6ES7634-1DF02-0AE3
Firmware version: V2.0.12
OP: OP17
Warranty: 6-Months Warranty
Product Line: Siemens c7-634
Rated value (DC): 24 V
Communications interface: MPI PROFIBUS-DP master or slave
Design as touch screen: No
Keyboard fonts: US English
Number of analog outputs 2


Related Siemens Simatic C7-634 Part No. :

Siemens C7-634 Description Inventory status
6ES7634-1DF00-0AE3 SIMATIC C7-634 In Stock
6ES7634-1DF01-0AE3 SIMATIC C7-634 In Stock
6ES7634-1DF02-0AE3 SIMATIC C7-634 Available Now
6ES7634-2BF00-0AE3 SIMATIC C7-634 In Stock
6ES7634-2BF01-0AE3 SIMATIC C7-634 In Stock
6ES7634-2BF02-0AE3 SIMATIC C7-634 Available Now
6ES7634-2DF00-0AE3 SIMATIC C7-634 In Stock

Siemens C7 634 series HMI Manuals PDF Download:

  • 6ES7634-1DF02-0AE3 SIMATIC HMI c7 634 datasheet pdf
  • Siemens Simatic c7-634 series HMI operator panel keypad manual


  • FAQ:

    Question: What is the size of 6ES7634-1DF02-0AE3 Siemens c7 634 membrane switch??

    Answer:It is 230 millimeters long and 193 millimeters wide.


    Question: How to repalce the Siemens C7 634?

    Answer:On-site repair of the C7 has not been provided for. For this reason, adefective C7 must be replaced
    1. Connect a programming device/PC to the multipoint interface.
    2. Use STEP 7 to save the user program on the C7 CPU to a programmingdevice/PC or remove the memory card on which the CPU user program isstored.
    If the C7 CPU is defective and the user program can no longer be readout, remove the C7 without any further safety measures.


    Question: What is the 6ES7634-1DF02-0AE3 Siemens C7-634 membrane switch price?

    Answer: Submit a fast quote, send VICPAS an email for best price.



    Common misspellings:

    6S7634-1DF02-0AE3
    6E7634-1DF02-0AE3
    6ES634-1DF02-0AE3
    6ES734-1DF02-0AE3
    6ES764-1DF02-0AE3
