F186033 DSI 20-0292 DTFP 92-8085 B5 Touchscreen Panel
| Categories | Panelview 1200 |
|---|---|
| Brand | VICPAS |
| Model | F186033 DSI 20-0292 DTFP 92-8085 B5 |
| Warranty | 365 Days |
| Brand | Rockwell Automation Allen Bradley |
| Product Line | Panelview 1200 |
| Supply | Panelview 1200 Terminals Touchscreen |
| Size | 12.1 inch |
| model | F186033 DSI 20-0292 DTFP 92-8085 B5 |
| Parts | Touchscreen Panel Glass Protective Film |
| Terms of Payment | Western Union, MoneyGram, T/T, Paypal, PayPal, Credit Card |
| Download DOC |  |
| Update Time | Apr 26,2024 |
F186033 DSI 20-0292 DTFP 92-8085 B5 Touchscreen Panel Glass Repair Replacement
The F186033 DSI 20-0292 DTFP 92-8085 B5 touch screen is a PanelView 1200 clip-mount operator terminal with a 12-inch display size and a 16-Color CRT. The interface comes with the user configurable 64 KB battery-backed RAM which can be upgraded to 128 KB. The panelview 1200 F186033 DSI 20-0292 DTFP 92-8085 B5’s display format includes 24 rows x 80 columns (normal size characters) while the touchscreen format includes a matrix of 120 touch cells (10 across by 12 high).
A PanelView 1200 F186033 DSI 20-0292 DTFP 92-8085 B5 terminal application file contains a series of screens and configurations which, when interpreted and executed by PanelView 1200, replace the functions of a control panel of buttons, switches and indicators. The screens are created on a development computer running PanelBuilder] Development Software or PanelBuilder] 1200 Configuration Software for Windows, and then saved in an application file on the development computer’s disk. The application file is then downloaded to a PanelView 1200 2711-TC1 terminal where it stays in battery-backed RAM.
The communication process includes a remote I/O and an RS-232 port. The module uses 90-264V AC at 47-63 Hz and has a NEMA 12 enclosure type. The 2711-TC1 includes PanelBuilder32 software for development and configuration.
VICPAS supply panelview 1200 2711-TC1 F186033 DSI 20-0292 DTFP 92-8085 B5 touchsreen and protective film. All of them with VICPAS 180 days warranty and support Urgent Worldwide Shipping.
Specifications:
The table below describes the parameters of the Panelview 1200 F186033 DSI 20-0292 DTFP 92-8085 B5 terminals Parts.
| Part Number: | F186033 DSI 20-0292 DTFP 92-8085 B5 |
| Display Size: | 12.1 inches |
| Display Color: | Amber |
| Warranty: | 180 days Warranty |
| Product Line: | Panelview 1200 |
| Input Type: | Touchscreen |
| Mounting Position: | vertical |
| Key Features: | Touch screen support |
| Language: | Worldwide |
| Enclosure Type: | NEMA 4X |
Related Allen Bradley Panelview 1200 Terminals Part No. :
| PanelView 1200 HMI | Description | Inventory status |
| 2711-KA1 | Allen Bradley PanelView 1200 Membrane Keypad Switch LCD | In Stock |
| 2711-KC1 | PanelView 1200 Keypad Membrane Switch LCD Display | Available Now |
| 2711-TA1 | Allen Bradley PanelView 1200 Touchscreen Front Overlay | In Stock |
| 2711-TC1 | PanelView 1200 HMI Touch Screen Protective Film | Available Now |
| 2711-TA4 | HMI Panel Glass Protective Film Front Overlay | Available Now |
| 2711-TC4 | PanelView 1200 Touch Screen Protective Film | In Stock |
| Allen Bradley PanelView 1200 | Description | Inventory status |
AB Panelview 1200 Manuals PDF Download:
FAQ:
Question: How to clean the AB Panelview F186033 DSI 20-0292 DTFP 92-8085 B5 Terminals Touch Screen?
Answer: To clean the touch screen, use ethyl alcohol (ethanol) on a cotton gauze pad. This is more efficient than isopropyl alcohol, (which leaves a slight residue upon first application), and safer than MEK (methyl ethyl ketone). MEK is harmless to the touch screen, but repeated applications will discolor the bezel if the paint surface is broken or scratched.
Question: What are the specifications of the AB Panelview 1200 terminal CRT display?
Answer: The following tables provide details of the display specifications.
Display Format: 24 Rows x 80 Columns (normal size characters)
Character Cell Pixel Format: 8 wide x 10 high
Display Alignment: User-configurable, stored in non-volatile memory, 12 character horizontal range, 2.4 character vertical range
Display Intensity: Low to high range adjustment on back of unit
Screen Saver: User-configurable, 1-999 minute timeout
Display Size: 12" Diagonal
Question: What is the size of F186033 DSI 20-0292 DTFP 92-8085 B5 Touchscreen?
Answer: The 2711-TC1 touchscreen glass is 12.1-inch.
Question: What is the F186033 DSI 20-0292 DTFP 92-8085 B5 Panelview 1200 HMI parts price?
Answer: Submit a fast quote, send VICPAS an email for best price.
