Delta DOP-A57CSTD Protective Film Touch Panel Repair
Delta DOP-A Series DOP-A57CSTD Protective Film Touch Digitizer Glass Replacement
VICPAS supply Delta DOP-A Series DOP-A57CSTD Protective Film and Touch Panel with 365 days warranty and support Urgent Worldwide Shipping.
Installation and Storage Conditions
The product should be kept in the shipping carton before installation. In order to retain the warranty coverage, the DOP-A57CSTD Touch Screen Front Overlay HMI should be stored properly when it is not to be used for an extended period of time. Some storage suggestions are:
Store in a clean and dry location free from direct sunlight.
Store within an ambient temperature range of -20°C to +60°C (-4°F to 140°F).
Store within a relative humidity range of 10% to 90% and non-condensing.
Do not store the DOP-A57CSTD Touch Digitizer Glass Protective Film HMI in a place subjected to corrosive gases and liquids.
Correctly packaged and placed on a solid and durable surface.
Do not mount the DOP-A57CSTD Front Overlay Touch Screen HMI adjacent to heat-radiating elements or in direct sunlight.
Do not mount the DOP-A57CSTD Protective Film Touch Panel HMI in a location subjected to corrosive gases, liquids, or airborne dust or metallic particles.
Do not mount the DOP-A57CSTD Touchscreen Panel Front Overlay HMI in a location where temperatures and humidity will exceed specification.
Do not mount the DOP-A57CSTD Touch Digitizer Protective Film HMI in a location where vibration and shock will exceed specification.
Do not mount the DOP-A57CSTD Front Overlay Touchscreen HMI in a location where it will be subjected to high levels of electromagnetic radiation.
The table below describes the parameters of the Delta DOP-A DOP-A57CSTD Front Overlay Touch Screen Monitor HMI Parts.
|Display Color:||256 Colors|
|Display Resolution:||320 x 240 pixels|
|Operation Voltage:||DC +24V (-10%~+20%)|
|Product Line:||Delta DOP-A|
|Display Type:||STN LCD|
|Operation Temperature:||0 °C ~ 50 °C|
|Storage Temperature:||-20 °C ~ +60 °C|
Related Delta DOP-A Series HMI Part No. :
|Delta DOP-A HMI||Description||Inventory status|
|DOP-A57BSTD||Delta DOP-A Series Touch Screen Protective Film Replacement||In Stock|
|DOP-A57CSTD||Delta DOP-A Series Protective Film Touch Panel Repair||Available Now|
|DOP-A57GSTD||Delta DOP-A Series Touchscreen Protective Film Repair||In Stock|
|DOP-A75CSTD||Delta DOP-A Series Protective Film HMI Panel Glass||Available Now|
|DOP-A80THTD1||Delta DOP-A Series Front Overlay Touch Screen Monitor||In Stock|
|DOP-A10TCTD||Delta DOP-A Series HMI Touch Screen Glass Protective Film||Available Now|
|DOP-A10THTD||Delta DOP-A Series Touch Screen Panel Front Overlay Repair||In Stock|
|DOP-A10THTD1||Delta DOP-A Series Front Overlay Touch Membrane||In Stock|
|Delta DOP-A Series||Description||Inventory status|
Delta DOP-A Series HMI Manuals PDF Download:
Question: Why won't the pitch compensation function of Delta's CNC DOP-A57CSTD Front Overlay Touch Panel controller work even after the amount of pitch compensation is set?
Answer: Currently Delta's CNC DOP-A57CSTD Panel Glass Protective Film controller provides the pitch compensation function for one-direction compensation only. One-direction means either forward or backward from the zero point (starting point) of the machine coordinates. If the compensation direction is not set correctly, the pitch compensation function application setup will not be enabled and work normally. For setting the compensation direction, please use the compensation parameter, 1006, and set Bit 15 to determine the direction.
