PP845 3BSE042235R1 Protective Film Glass Screen Repair

PP845 3BSE042235R1 Protective Film Glass Screen Repair

PP845 3BSE042235R1 Protective Film Glass Screen Repair
PP845 3BSE042235R1 Protective Film Glass Screen RepairPP845 3BSE042235R1 Protective Film Glass Screen RepairPP845 3BSE042235R1 Protective Film Glass Screen RepairPP845 3BSE042235R1 Protective Film Glass Screen RepairPP845 3BSE042235R1 Protective Film Glass Screen Repair
CategoriesABB Panel 800
BrandVICPAS
ModelPP845 3BSE042235R1
Warranty365 Days
Product LineABB Panel 800
TypesTouch Panel Glass and Protective Film
Shipping2-3 workdays
Size10.4 inches
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, MoneyGram, T/T, Paypal, PayPal, Credit Card
Download DOCpdf icon
Update TimeApr 22,2024
Detail Information

ABB Panel 800 PP845 3BSE042235R1 Front Overlay Touch Digitizer Glass Repair

Order each part separately is available

ABB PP845 3BSE042235R1 Front Overlay Touch Panel Repair

The Panel 800 operator panel is developed to satisfy the demands of humanmachine communication. Built-in functions such as displaying and controlling text, dynamic indication, time channels, alarm and recipe handling are included.


The operator panel work, for the most part, in an object-oriented way, making it easy to understand and use. The configuration operation of the panel is made in a personal computer, using the configuration tool Panel Builder 800. The project is then transferred and stored in the PP845 3BSE042235R1 operator panel.


The PP845 3BSE042235R1 operator panel can be connected to many types of automation equipment, such as PLCs, servos or drives.


VICPAS supply ABB Panel 800 PP845 3BSE042235R1 Touch Screen Panel and Protective Film with 365 Days warranty and support Urgent Worldwide Shipping.






Specifications:

The table below describes the parameters of the PP845 3BSE042235R1 ABB Panel 800.

Part Number: PP845 3BSE042235R1
Touch Material: Polyester on glass
Part Type: New
Backlight: LED
Warranty: 365 Days
Diagonal (inches): 3.8” widescreen
Overlay Material: Autotex F157/F207 *
Active Area Of Display: 70.1 x 52.6 mm
Display Resolution: 320 × 240 pixels
Display Type: TFT-LCD


Related ABB Panel 800 Terminals Part No. :

ABB Panel 800 Description Inventory status
PP815A 3BSE042239R1 ABB Panel 800 PP815A Front Overlay Touch Membrane In Stock
PP815A 3BSE042239R2 ABB Panel 800 Series PP815A Touch Glass Front Overlay Repair In Stock
PP820A 3BSE042243R1 ABB Panel 800 Series PP820A Membrane Keyboard Keypad Repair Available Now
PP820A 3BSE042243R2 ABB Panel 800 PP820A HMI Panel Glass Protective Film Available Now
PP825A 3BSE042240R1 ABB Panel 800 Series PP825A Touch Screen Monitor Front Overlay In Stock
PP826 3BSE042244R1 ABB Panel 800 Series PP826 Membrane Keypad Switch Replacement In Stock
PP826A 3BSE042244R3 ABB Panel 800 Series PP826A HMI Operator Panel Keypad Available Now
PP835 3BSE042234R1 ABB Panel 800 Series PP835 Protective Film Touchscreen Repair In Stock
PP835A 3BSE042234R2 ABB Panel 800 Series PP835A HMI Protective Film Touch Screen Glass Available Now
PP836 3BSE042237R1 ABB Panel 800 Series PP836 Operator Keyboard Replacement Repair In Stock
PP836A 3BSE042237R2 ABB Panel 800 Series PP836A Switch Membrane Repair Replacement In Stock
Panel 800 Repair Description Inventory status

ABB Panel 800 HMI Manuals PDF Download:

  • Panel 800 PP845 3BSE043447R501 en 5.1 Hardware and Installation

  • FAQ:

    Question: How to install the PP845 3BSE042235R1 operator terminal?

    Answer:

    1. Unpack and check the delivery. If damage is found, notify the supplier.

    ABB PP845 3BSE042235R1 Touch Panel Front Overlay Repair

    2. Disconnect the PP845 3BSE042235R1 operator panel from the power supply.

    3. Remove the plastic cover from the expansion port.

    ABB PP845 3BSE042235R1 Touch Panel Front Overlay Repair

    4. Secure the expansion module in position, using the provided screws.

    5. Connect the PP845 3BSE042235R1 operator panel to the power supply.


    Question: How to ground the PP845 3BSE042235R1 operator panel?

    Answer:

    1. The operator panel’s mounting clamps do not provide a secure grounding connection between the panel and the device cabinet.

    2. Connect a 2.5 mm² wire between the operator panel’s quick-connect plinth and the panel chassis.

    3. Connect a 6 or 4 mm² wire or grounding braid between the panel’s chassis and the closest grounding point on the door.

    4. Connect a strong but short grounding braid between the door and the device cabinet.

    5. Twist the cables onto the 24 V DC feed.

    6. A ferrite core suppresses disturbances to the 24 V feed. 2 turns around the ferrite core provide 4 times the suppression of 1 turn. 3 turns around the ferrite core provide 9 times the suppression of 1 turn.
