B&R 4PP151.1505-31 Operator Panel Keypad

B&R 4PP151.1505-31 Operator Panel Keypad

B&R 4PP151.1505-31 Operator Panel Keypad
CategoriesPower Panel 100/200
Size15 inch
ModelB&R Power Panel 100 4PP151.1505-31
ShippingDHL/FedEx/UPS/TNT/EMS/Aramex /DPEX
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, T/T, PayPal, Credit Card
Update TimeApr 24,2024
Detail Information

B&R Power Panel 100 4PP151.1505-31 Keyboard Membrane Repair Replacement

Power Panel 100 4PP151.1505-31 Keyboard Membrane

The visualization project runs on the Power Panel 100. Serial RS232 or Ethernet TCP/IP provides the communication to the controller system. Flexible programming with frame drivers or Ethernet socket services allows a connection to be made to any control system. I/O peripherals and drives are connected to the controller.

B&R Automation Runtime guarantees a uniform runtime environment for Automation Studio programs on all target systems. This ensures uniform programming and operation on all devices. Automation Runtime possesses a multitasking operating system adapted specially for use with control technology. The cycle time for your application can be separated among several task classes. Automation Runtime ensures that all application programs are executed within defined time periods, proving itself to be a configurable, deterministic real-time multitasking system. An extensive project can be divided into small individual tasks. This way of working increases modularity and makes it much easier to maintain projects.

  Contact Best Price


The table below describes the parameters of the 4PP151.1505-31 Power Panel 100 Membrane Keyboard Keypad.

Part Number : 4PP151.1505-31
Product Line:Power Panel 100
Screen diagonal10.4 in
Warranty: 365 Days Warranty
Input Power24 VDC
Display Type:TFT color
Mounting position: Vertical
Input Type: Keypad
Serial interface Type:RS232
Storage -20 to 70°C

Related Power Panel 100 Series Part No. :

Power Panel 100 Description Inventory status
4PP120.1043-K05 B&R Power Panel 100 Touch Screen Panel Glass Protective Film In Stock
4PP120.1043-K06 PP100 B and R Touch Panel Glass Front Overlay Repair Available Now
4PP151.1043-31 B&R Power Panel 100 Operator Panel Keypad Repair In Stock
4PP152.1043-31 B and R Power Panel 100 Membrane Keypad Switch Replacement In Stock
4PP180.1043-31 PP100 B&R Membrane Keypad Touch Screen Front Overlay In Stock
4PP181.1043-31 B and R Power Panel 100 Keypad Membrane Repair In Stock
4PP182.1043-31 PP100 B&R Membrane Keypad Keyboard Replacement Available Now
4PP120.1505-31 Power Panel 100 B&R Membrane Keypad Switch Touch Panel Protective Film In Stock
4PP151.1505-31 B and R Power Panel 100 Operator Panel Keypad Available Now
4PP180.1505-31 B&R Power Panel 100 Keypad Membrane Touch Screen Front Overlay In Stock
4PP181.1505-31 Power Panel 100 B and R Keypad Membrane Repair Available Now
B and R PP100 Description Inventory status


Question:What are the functions of B&R Automation Device Interface (ADI) - Control Center?

Answer: The functions provided by the Automation Device Interface (ADI) - Control Center vary according to the device series.
To carry out a firmware upgrade, the following steps should be taken:
• Changing display-specific parameters
• Reading device-specific keys
• Updating the key configuration
• Enabling device-specific LEDs on a membrane keypad or keys
•Reading and calibrating control devices (e.g. key switches, handwheels, joysticks, potentiometers)
• Reading temperatures, fan speeds, statistical data and switch settings
• Reading operating hours (power-on hours)
• Reading user and factory settings
• Reading software versions
• Updating and backing up BIOS and firmware
• Creating reports about the current system (support assistance)
• Setting the SDL equalizer value when adjusting SDL cables
• Changing the user serial ID

Question:How can Power Panel 100 4PP151.1505-31 screen burn-in be avoided?

• By constantly changing between static and dynamic images
• By avoiding excessive brightness differences between foreground and background elements
• By using colors with similar brightness
• By using complementary colors in follow-up images
• By using a screensaver

Question:What causes B&R 4PP151.1505-31 image sticking?

• Static images
• Screensaver not enabled
• Sharp contrast transitions (e.g. black / white)
• High ambient temperatures
• Operation outside of the specifications
