Membrane keyboard for XBTF023110 membrane keypad switch

Membrane keyboard for XBTF023110 membrane keypad switch

Membrane keyboard for XBTF023110 membrane keypad switch
Membrane keyboard for XBTF023110 membrane keypad switchMembrane keyboard for XBTF023110 membrane keypad switchMembrane keyboard for XBTF023110 membrane keypad switch
CategoriesMagelis XBT F/FC
BrandVICPAS
ModelXBTF023110
BrandSchneider
Warranty365 Days
SupplyXBTF023110 Magelis Membrane keypad keyboard
Size9.4 inch
Product LineSchneider XBT F Series
Terms of PaymentWestern Union, T/T, PayPal, T/T ,Credit Card, Western Union
Download DOC
Update Time2022/7/7
Detail Information

Schneider Magelis HMI XBTF023110 HMI Membrane Keyboard Keypad Repair Part


Schneider Magelis HMI XBTF023110 Membrane Keypad Switch Repair Kit

Magelis Schneider XBTF023110 Keypad Membrane Terminal Features:
• Terminals with LCD screen.
• STN Monochrome
• 640x480 pixels.
• 12 static function keys.
• 10 dynamic function keys.
• System and alphanumeric keys.
• Downloadable protocols.
• Printer output


The brightness and contrast of the screen can be adjusted. For Schneider Magelis XBTF023110 Membrane Keypad Keyboard terminals with keyboard, the adjustments are identical to those performed using the keyboard keys. On XBTF023110 Magelis HMI touchscreen terminals, brightness and contrast can be adjusted using the touch zones (depending on screen technology). A clearing page is provided on touchscreen terminals for de-activating the touchscreen pad in order to clear the screen surface. Simultaneously press the two opposite touch zones to re-activate the pad and exit the clearing page.





Specifications:

The table below describes the parameters of the XBTF023110 Schneider Magelis Membrane Keypad Switch.

Part Number: XBTF023110
Display device: STN monochrome LCD
Display diagonal: 9.5 in
Warranty: 365 Days
Product Line: Schneider XBT F Series
Rated Voltage: DC 5V 1mA
Operating Temp.: -10℃~+80℃
Storage Temp.: -20℃~+70℃
Conductive Trace: Silver or Copper
Life Cycle: 5 Million Cycles(up to)


Related Schneider XBT F Series Part No. :

Magelis XBT F Series Description Inventory status
XBTF011110 Operator Terminals with 5.7-inch Operator Keypad In Stock
XBTF011310 5.7-inch Terminals with Membrane Keypad Switch In Stock
XBTF011310TA Operator Terminals 5.7'' Terminal Keypad Available Now
XBTF023110 9.5-inch Terminals with Keypad Switch In Stock
XBTF023310 Operator Terminals with 9.5'' Terminal Keypad Call
XBTF024110 Operator Terminals with Membrane keypad Keyboard In Stock
XBTF024310 Terminals keyboard with 10.4'' Graphic touchscreen In Stock
XBTF024510 Operator Terminals Switch with 10.4 in. Graphic Panel In Stock
XBTF024510PR Operator Terminals Switch with 10.4 in. Graphic Panel In Stock
XBTF024610 Terminals Keypad with 10.4 in. Graphic Panel Available Now
XBTF032110 5.7'' Graphic Panel Touchscreen Protective Film In Stock
XBTF032310 Operator Terminals 5.7'' Graphic Touch Panel Available Now
XBTF032310TA Protective Film 5.7'' Graphic Panel Glass Available Now
XBTF034310 Operator Terminals 10.4 Graphic Touch Screen In Stock
XBTF034110 Terminals 10.4 Graphic Touchscreen Overlay In Stock
XBTF034510 12.3'' Front Overlay Touchscreen Panel In Stock
XBTF034610 Protective Film 12.3'' Graphic Touch Screen Call
XBTF10CK Membrane Keypad for Operator Panel In Stock
Magelis XBT F Description Inventory status


Schneider XBT HMI Manuals PDF Download:

  • Schneider Legacy Products_XBTF023110 PDF
  • Schneider MAGELiS® Operator Terminals Guide
  • Schneider MAGELiSä XBT Operator Interface Brochure
  • Telemecanique XBT-F TXBT-F Instruction Manual
  • Schneider XBT-F TXBT-F User manual

  • FAQ:

    Question: What is the size of XBTF023110 Keyboard Membrane?

    Answer: The Schneider Terminal XBTF023110 Keyboard Membrane is 9.5-inch.


    Question: What is the keys type for the Schneider XBTF023110 HMI Terminal?

    Answer: The Magelis XBT F023110 has multiple static and dynamic keys on keypad units.


    Question: Is the keyboard of the unit replaceable?

    Answer: Yes, the membrane keypad of XBTF023110 can be replaceable.



    Common misspellings:

    XBTF23110
    BTF023110
    XBTF032110
    XBTF023l10
    XBTF0023110
