6AV6545-0CA10-0AX0 Siemens SIMATIC TP270 Touch Panel

6AV6545-0CA10-0AX0 Siemens SIMATIC TP270 Touch Panel
6AV6545-0CA10-0AX0 Siemens SIMATIC TP270 Touch Panel
6AV6545-0CA10-0AX0 Siemens SIMATIC TP270 Touch Panel6AV6545-0CA10-0AX0 Siemens SIMATIC TP270 Touch Panel6AV6545-0CA10-0AX0 Siemens SIMATIC TP270 Touch Panel
CategoriesTouch Panel
AlbumView larger image
Warranty365 Days
Product LineTP270
SupplySiemens TP270 HMI Touch Panel and Protecitve film
Size5.7 inch
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, MoneyGram, T/T, Paypal, PayPal, Credit Card
Download DOC
Update Time2020-05-27
Detail Information

6AV6545-0CA10-0AX0 Siemens SIMATIC HMI TP270 Touch Screen Panel, Overlay, Front Cover and LCD Display Repair Replacement

6AV6545-0CA10-0AX0 SIMATIC TP 270 6" Touch panel 5.7" STN color display 2 MB configuration memory, configurable with ProTool From Version V6.0

The panels TP 270 and OP 270 are downgraded models and less expensive, but still provide convincing functionality. The HMI devices not only support the classic HMI applications (visualization with WinCC flexible) but also additional applications, such as process diagnostics (ProAgent).

The comprehensive product range allows users to choose the HMI device most suited to their needs. All HMI devices include the following advantages:
• High degree of configuration efficiency
• Configuration simulation on the configuration computer - no PLC required
• Clear display and easy process operation using a Window-Based user interface
• Large selection of predefined screen objects for use during configuration
• Dynamic screen objects, e.g. moving objects
• Uncomplicated and quick handling of recipes and data records in recipe screens and recipe views
• Logging of alarms, process values and login/logout procedures
• Creation of vector graphics using the WinCC flexible configuration software without an external graphics editor,
• Standard connections to SIMATIC S5/DP, SIMATIC S7 and SIMATIC 505, as well as to PLCs from other manufacturers

VICPAS supply 6AV6545-0CA10-0AX0 Siemens TP270 touch panel, Overlay and LCD display. All of them with VICPAS 365 days warranty and support Urgent Worldwide Shipping.

  Contact Best Price


The table below describes the parameters of the 6AV6545-0CA10-0AX0 Siemens TP270 HMI Parts.

Part Number : 6AV6545-0CA10-0AX0
Size 5.7 inch;
Warranty: 365 days Warranty
Product Line:Siemens TP270
Resolution:640 x 480;
Number of colors: 256
Control elements: Touch screen
MTBF:60 000 h
PLC Connection: SIMATIC S7-200

Related Simatic TP270 Part No. :

Siemens TP270 6" Description Inventory status
6AV6545-0CA10-0AX0 TP270 6 STN In Stock
6AV6545-0CA10-0AX1 TP270 6 In Stock
6AV6545-0CA10-2AX0 TP270 6 In Stock
SIMATIC HMI TP270 6"  Description Inventory status

Siemens TP270 HMI Manuals PDF Download:

  • 6AV6545-0CA10-0AX0 Siemens TP270 datasheet pdf
  • Siemens Simatic TP270 Panel manual

  • FAQ:

    Question: What is the dimension of the Siemens TP270 Touchscrenn?

    Answer:The touchscreen of 6AV6545-0CA10-0AX0 SIMATIC TP270 is 5.7 inch,with 234.5 millimeter long and 181.5 millimeter wide

    Question: How to configure with the software WinCC flexible?

    Answer:In order to operate a machine or system using an HMI device, the user interface must be configured for the HMI device. This procedure is referred to as the "configuration phase".

    Question: What is the 6AV6545-0CA10-0AX0 Siemens TP270 HMI parts price?

    Answer: Submit a fast quote, send VICPAS an email for best price.
