6AV6545-8CC10-0AA0 Siemens Touch Panel TP270 10" Touchscreen

6AV6545-8CC10-0AA0 Siemens Touch Panel TP270 10" Touchscreen

6AV6545-8CC10-0AA0 Siemens Touch Panel TP270 10" Touchscreen
6AV6545-8CC10-0AA0 Siemens Touch Panel TP270 10" Touchscreen6AV6545-8CC10-0AA0 Siemens Touch Panel TP270 10" Touchscreen6AV6545-8CC10-0AA0 Siemens Touch Panel TP270 10" Touchscreen6AV6545-8CC10-0AA0 Siemens Touch Panel TP270 10" Touchscreen6AV6545-8CC10-0AA0 Siemens Touch Panel TP270 10" Touchscreen
CategoriesTouch Panel
BrandVICPAS
Model6AV6545-8CC10-0AA0
Warranty365 Days
BrandSiemens
Product LineTP270
SupplySiemens TP270 HMI Touch Panel and Protecitve film
Size10.4 inch
model6AV6545-8CC10-0AA0
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, MoneyGram, T/T, Paypal, PayPal, Credit Card
Download DOCpdf icon
Update TimeJanuary 31,2023
Detail Information

6AV6545-8CC10-0AA0 Siemens SIMATIC HMI TP270 10" Touch Screen Panel, Overlay, Front Cover and LCD Display Repair Replacement

Order each part separately is available

6AV6545-8CC10-0AA0 Siemens SIMATIC HMI TP270 10 Touch Screen Panel, Overlay, Front Cover and LCD Display Repair Replacement


6AV6545-8CC10-0AA0 SIMATIC Touch Panel TP 270 10.4" color STN display, Touch Stainless steel front, Continuous decorative film, Degree of protection front IP66 Windows CE 3.0 configurable with ProTool Version V6.0+SP2 or higher



The panels TP 270 and OP 270 are downgraded models and less expensive, but still provide convincing functionality. The HMI devices not only support the classic HMI applications (visualization with WinCC flexible) but also additional applications, such as process diagnostics (ProAgent).


The comprehensive product range allows users to choose the HMI device most suited to their needs. All HMI devices include the following advantages:
• High degree of configuration efficiency
• Configuration simulation on the configuration computer - no PLC required
• Clear display and easy process operation using a Window-Based user interface
• Large selection of predefined screen objects for use during configuration
• Dynamic screen objects, e.g. moving objects
• Uncomplicated and quick handling of recipes and data records in recipe screens and recipe views
• Logging of alarms, process values and login/logout procedures
• Creation of vector graphics using the WinCC flexible configuration software without an external graphics editor,
• Standard connections to SIMATIC S5/DP, SIMATIC S7 and SIMATIC 505, as well as to PLCs from other manufacturers


VICPAS supply 6AV6545-8CC10-0AA0 Siemens TP270 touch panel, Overlay and LCD display. All of them with VICPAS 365 days warranty and support Urgent Worldwide Shipping.






Specifications:

The table below describes the parameters of the 6AV6545-8CC10-0AA0 Siemens TP270 HMI Parts.

Part Number : 6AV6545-8CC10-0AA0
Size 10.4 inch;
Display STN
Warranty: 365 days Warranty
Product Line: Siemens TP270
Resolution: 640 x 480;
Number of colors: 256
Control elements: Touch screen
MTBF: 60 000 h
PLC Connection: SIMATIC S7-200


Related Simatic TP270 Part No. :

Siemens TP270 10" Description Inventory status
6AV6545-0CC10-0AX0 TP270 10 STN In Stock
6AG1545-0CC10-4AX0 SIPLUS HMI TP270 10" Touch In Stock
6AV6545-8CC10-0AA0 TP270 10 TOUCH, STAINLESS STEEL FRONT In Stock
SIMATIC HMI TP270 10" Description Inventory status

Siemens TP270 HMI Manuals PDF Download:

  • 6AV6545-8CC10-0AA0 Siemens TP270 datasheet pdf
  • Siemens Simatic TP270 Panel manual


  • FAQ:

    Question: What is the dimension of the Siemens TP270 Touchscrenn?

    Answer:The touchscreen of 6AV6545-8CC10-0AA0 SIMATIC TP270 is 10.4 inch,with 234.5 millimeter long and 181.5 millimeter wide


    Question: How to configure with the software WinCC flexible?

    Answer:In order to operate a machine or system using an HMI device, the user interface must be configured for the HMI device. This procedure is referred to as the "configuration phase".


    Question: What is the 6AV6545-8CC10-0AA0 Siemens TP270 10" HMI parts price?

    Answer: Submit a fast quote, send VICPAS an email for best price.


    Common misspellings:

    6V6545-8CC10-0AA0
    6A6545-8CC10-0AA0
    6AV545-8CC10-0AA0
    6AV645-8CC10-0AA0
    6AV655-8CC10-0AA0
