6AV6643-0AA01-1AX1 Siemens SIMATIC HMI TP277 Touch Panel

6AV6643-0AA01-1AX1 Siemens SIMATIC HMI TP277 Touch Panel

6AV6643-0AA01-1AX1 Siemens SIMATIC HMI TP277 Touch Panel
6AV6643-0AA01-1AX1 Siemens SIMATIC HMI TP277 Touch Panel6AV6643-0AA01-1AX1 Siemens SIMATIC HMI TP277 Touch Panel6AV6643-0AA01-1AX1 Siemens SIMATIC HMI TP277 Touch Panel6AV6643-0AA01-1AX1 Siemens SIMATIC HMI TP277 Touch Panel6AV6643-0AA01-1AX1 Siemens SIMATIC HMI TP277 Touch Panel
CategoriesTouch Panel
BrandVICPAS
Model6AV6643-0AA01-1AX1
Warranty365 Days
BrandSiemens
Product LineTP277
SupplySiemens TP277 HMI Touch Panel and Protecitve film
Size5.7 inch
model6AV6643-0AA01-1AX1
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, MoneyGram, T/T, Paypal, PayPal, Credit Card
Download DOCpdf icon
Update TimeApr 22,2024
Detail Information

6AV6643-0AA01-1AX1 Siemens SIMATIC HMI TP277 Touch Screen Panel, Overlay, Power Supply Connector, Mounting Clips, Plastic Case, LCD Gasket, Case Gasket, Screws and LCD Display Repair Replacement

Order each part separately is available


6AV6643-0AA01-1AX1 Siemens SIMATIC HMI TP277 Touch Screen Panel, Overlay, Case Gasket, LCD Gasket, Power Supply Connector, Plastic Cover Body, Mounting Clips, Screws and LCD Display Repair Replacement


6AV6643-0AA01-1AX1 SIMATIC TP 277 6" Touch panel 5.7" TFT display 4 MB configuration memory, configurable with WinCC flexible 2005Standard


The HMI devices TP 277 and OP 277 represent a further stage of development of the HMI devices TP 270-6 and OP 270-6.


The HMI devices are based on the standard operating system Microsoft Windows CE. Compared with the Multi Panel MP 277, the TP 277 and the OP 277 offer an inexpensive scale option. The mounting options and the functional scope of the TP 277 and OP 277 are compatible with the HMI devices in the 270 series.
The TP 277 and OP 277 also have the following features:
• The HMI devices can be operated on PROFINET via the Ethernet port.
• The HMI devices feature a TFT screen with 256 colors.
• The use of projects with scripts and logs is supported.


VICPAS supply 6AV6643-0AA01-1AX1 Siemens TP277 touch panel, Overlay, Mounting Clips, Power Supply Connector, LCD Gasket, Case Gasket, Plastic Cover, Screws and LCD display. All of them with VICPAS 365-day warranty and support Urgent Worldwide Shipping.






Specifications:

The table below describes the parameters of the 6AV6643-0AA01-1AX1 Siemens TP277 HMI Parts.

Part Number : 6AV6643-0AA01-1AX1
Size 5.7 inch;
Display TFT
Warranty: 365 days Warranty
Product Line: Siemens TP277
Resolution: 320 x 240;
Number of colors: 256
Control elements: Touch screen
MTBF: 60 000 h
PLC Connection: SIMATIC S7-200


Related Simatic TP277 Part No. :

Siemens TP277 Description Inventory status
6AV6643-0AA01-1AX1 TP277 6 In Stock
6AG1643-0AA01-4AX0 SIPLUS TP277 6 TOUCH In Stock
6AV6643-0AA01-1AX0 SIMATIC TP 277 6" In Stock
SIMATIC TP277 Description Inventory status

Siemens TP277 HMI Manuals PDF Download:

  • 6AV6643-0AA01-1AX1 Siemens TP277 datasheet pdf
  • Siemens Simatic TP277 Panel manual


  • FAQ:

    Question: What is the dimension of the Siemens TP277 Touchscrenn?

    Answer:The touchscreen of 6AV6643-0AA01-1AX1 SIMATIC TP277 is 5.7 inch,with 138.1 millimeter long and 109.4 millimeter wide


    Question: How to backup and restore the Siemens SIMATIC TP277?

    Answer:You can back up and restore the following data found in the internal flash memory of the HMIdevice with a PC:br/>• Project and HMI device image
    • Password listbr/>• Recipe databr/>Use one of the following tools for backup and restore:br/>• WinCC flexiblebr/>• ProSave


    Question: What is the 6AV6643-0AA01-1AX1 Siemens TP277 HMI parts price?

    Answer: Submit a fast quote, send VICPAS an email for best price.
