6FC5203-0AF02-0AA0 Siemens SINUMERIK OP012 Membrane Keyboard

6FC5203-0AF02-0AA0 Siemens SINUMERIK OP012 Membrane Keyboard

6FC5203-0AF02-0AA0 Siemens SINUMERIK OP012 Membrane Keyboard
6FC5203-0AF02-0AA0 Siemens SINUMERIK OP012 Membrane Keyboard6FC5203-0AF02-0AA0 Siemens SINUMERIK OP012 Membrane Keyboard6FC5203-0AF02-0AA0 Siemens SINUMERIK OP012 Membrane Keyboard
CategoriesSINUMERIK Operator Panel
BrandVICPAS
Model6FC5203-0AF02-0AA0
BrandSiemens
Warranty6 Months
Product LineSiemens OP012 Operator Panel
SupplySinumer HMI OP012 Membrane Keyboard Plastic Case
size12.1 inch
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, MoneyGram, T/T, Paypal, PayPal, T/T ,Credit Card, Western Union
Update TimeJun 17,2024
Detail Information

6FC5203-0AF02-0AA0 Siemens SINUMERIK HMI OP012 OPERATOR PANEL Operator Panel Keypad and Plastic Shell Housing Repair Replacement


6FC52030AF020AA0 Siemens SINUMERIK HMI OP012 OPERATOR PANEL Membrane Switch and Plastic Case Cover Repair Replacement


Description of Siemens 6FC5203-0AF02-0AA0 Terminal Keypad
The SINUMERIK OP 012 6FC52030AF020AA0 operator panel front and 12.1"TFT color display with a resolution of 800 x 600 pixels (SVGA) feature a 59-key membrane keypad as well as 2 x(8+2) horizontal and 2 x 8 vertical softkeys. The 2 x 8 vertical softkeys can be used as direct keys. The optional SINUMERIK 6FC5 203-0AF02-0AA0 Operator Panel Keypad direct key module provides an additional connection of the 2 x 8 vertical softkeys as direct keys to the PROFIBUS DP, if no pushbutton panel or machine control panel with connection of the direct keys is available. Securing is done from the rear using special clamps that are included in the delivery kit.

Compliance with the connection conditions of Siemens 6FC52030AF020AA0 Membrane Keyboard Keypad
The controller is tested for compliance with the ambient conditions specified below. Trouble-free operation is only ensured if:
• These ambient conditions of 6FC5 203-0AF02-0AA0 Switch Membrane are maintained when storing, transporting and operating the equipment.
• Original components and spare parts are used. This applies in particular to the use of specified cables and plug connectors.
• The equipment of 6FC5203-0AF02-0AA0 Membrane Keypad Switch is correctly installed and commissioned.

DANGER
The equipment may not be commissioned until it has been clearly identified that the machine in which the controller is installed, is in full conformance with the specifications in EC Directive 98/37/EC.




Specifications:

The table below describes the parameters of the 6FC5 203-0AF02-0AA0 Siemens OP012 HMI Parts.

Mounting Format: 19''
Protection: IP 65
Combination: PCU, TCU, Videolink Receiver
Product Line: Siemens OP012
Softkeys: 2 x 8 Horizontal Rows
Flat Screen: 12.1 in TFT
Resolution: 800 x 600 Pixels
Part Number: 6FC5203-0AF02-0AA0
Design of Display: LC Display
Power Supply: Status LEDs


Related Simatic OP012 Part No. :

SINUMERIK OP012 Keypad Description Inventory status
6AU1350-2AH23-1BE1 Siemens SINUMERIK HMI OP012T Terminal Keypad Repair In Stock
6FC5203-0AF02-0AA0 Siemens OP012 Membrane Switch Replacement Available Now
6FC5203-0AF02-0AA1 Siemens SINUMERIK Operator Keyboard Repair In Stock
6FC5203-0AF02-0AA2 Siemens SINUMERIK HMI OP012 Keypad Membrane Replacement In Stock
6FC5203-0AF06-1AA0 Siemens OP012T Membrane Keypad Switch Repair Available Now
6FC5203-0AF07-0AA0 Siemens SINUMERIK Keyboard Membrane Replacement In Stock
6FC5203-0AF52-0AA0 Siemens SINUMERIK HMI OP012 Terminal Keypad Repair Available Now
6FC5210-0DF22-0AA0 Siemens OP012 Switch Membrane Repair Available Now
6FC5248-0AF02-0AA0 Siemens SINUMERIK HMI OP012 Membrane Keypad Replacement In Stock
6FC5248-0AF02-0AA2 Siemens SINUMERIK HMI OP012 Membrane Keypad Replacement In Stock
Siemens OP012 Part No. Description Inventory status


Siemens OP012 series HMI Manuals PDF Download:


FAQ:

Question: How to connect operator panel 6FC5203-0AF02-0AA0?

Answer: The ribbon cable for the 6FC52030AF020AA0 operator panel front is inserted through the cut-out in the casing. Here, the switching states of the vertical direct control keys can be picked up without intermediate firmware. These signals can be evaluated in the direct control key module. Direct control key interface X11 on the keyboard controller for the operator panel front: per DIN 41651, plug connector, cable length max.0.5 m.


Question: How to combine with OP 012 6FC5 203-0AF02-0AA0?

Answer: The OP 012 6FC5203-0AF02-0AA0 outputs the signals from the direct control keys at connector X11(3).
How to combine with OP 012 6FC5 203-0AF02-0AA0?

Common misspellings:

FC5203-0AF02-0AA0
6FC5203-0A02-0AA0
6FC5203-0AF02-0AA
6FC52033-0AF02-0AA0
6FC5230-0AF02-0AA0
