PP826A 3BSE042244R3 5.7'' Keypad Membrane Repair

PP826A 3BSE042244R3 5.7'' Keypad Membrane Repair

PP826A 3BSE042244R3 5.7'' Keypad Membrane Repair
CategoriesPanel 800
ModelPP826A 3BSE042244R3
Warranty365 Days
Product LinePanel 800
TypesMembrane Keypad Switch
Shipping2-3 workdays
Size5.7 inches
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, MoneyGram, T/T, Paypal, PayPal, Credit Card
Update TimeJul 14,2024
Detail Information

Panel 800 PP826A 3BSE042244R3 Membrane Keypad Switch Repair Replacement

PP826A 3BSE042244R3 Membrane Keypad Switch Repair

The Panel 800 operator panel is developed to satisfy the demands of humanmachine communication. Built-in functions such as displaying and controlling text, dynamic indication, time channels, alarm and recipe handling are included.

The operator panel work, for the most part, in an object-oriented way, making it easy to understand and use. The configuration operation of the panel is made in a personal computer, using the configuration tool Panel Builder 800. The project is then transferred and stored in the PP826A 3BSE042244R3 operator panel.

The PP826A 3BSE042244R3 operator panel can be connected to many types of automation equipment, such as PLCs, servos or drives.

VICPAS supply Panel 800 PP826A 3BSE042244R3 Operator Panel Keypad with 365 Days warranty and support Urgent Worldwide Shipping.


The table below describes the parameters of the PP826A 3BSE042244R3 Panel 800.

Part Number: PP826A 3BSE042244R3
Backlight: CCFL
Display Type: STN-LCD
Part Type: New
Warranty: 365 Days
Display Resolution: 320 × 240 pixels
Active Area Of Display: 115.2 x 86.4 mm
Relative Humidity: 5 - 85 % non-condensed
NEMA: 4x indoor use only
Size: 5.7 inches

Related Panel 800 Terminals Part No. :

Panel 800 Description Inventory status
PP825A 3BSE042240R3 Panel 800 Series PP825A Touch Screen Protective Film Replacement In Stock
PP845 3BSE042235R1 Panel 800 PP845 Front Overlay Touch Membrane Repair In Stock
PP845A 3BSE042235R2 Panel 800 Series PP845A Touch Glass Front Overlay Repair In Stock
PP846 3BSE042238R1 Panel 800 Series PP846 Terminal Keypad Replacement Repair Available Now
PP846A 3BSE042238R2 Panel 800 PP846A HMI Membrane Keyboard Replacement Available Now
PP865 3BSE042236R1 Panel 800 Series PP865 Touch Screen Monitor Front Overlay In Stock
PP865A 3BSE042236R2 Panel 800 Series PP865A Front Overlay MMI Touch Screen Replacement In Stock
PP865S 3BSE042242R1 Panel 800 Series PP865S HMI Touch Screen Protective Film Available Now
PP871 3BSE069270R1 Panel 800 Series PP871 Protective Film Touchscreen Repair In Stock
PP871 3BSE069270R2 Panel 800 Series PP871 HMI Protective Film Touch Screen Glass Available Now
PP874 3BSE069271R1 Panel 800 Series PP874 Front Overlay Touch Screen Panel Repair In Stock
Panel 800 Repair Description Inventory status

Panel 800 HMI Manuals PDF Download:

  • Compact Product Suite Pane 800 5.1 Data sheet
  • 3BSE049348R301 Panel 800 PP826 Hardware and Installation

  • FAQ:

    Question: How to ground the PP826A 3BSE042244R3 operator panel?


    1. The operator panel’s mounting clamps do not provide a secure grounding connection between the panel and the device cabinet.

    2. Connect a 2.5 mm² wire between the operator panel’s quick-connect plinth and the panel chassis.

    3. Connect a 6 or 4 mm² wire or grounding braid between the panel’s chassis and the closest grounding point on the door.

    4. Connect a strong but short grounding braid between the door and the device cabinet.

    5. Twist the cables onto the 24 V DC feed.

    6. A ferrite core suppresses disturbances to the 24 V feed. 2 turns around the ferrite core provide 4 times the suppression of 1 turn. 3 turns around the ferrite core provide 9 times the suppression of 1 turn.

    Question: What is the price of PP826A 3BSE042244R3 Keyboard Membrane?

    Answer: Submit a fast quote, send VICPAS an email for best price.

    Question: What is the size of the PP826A 3BSE042244R3 Membrane Switch?

    Answer: The PP826A 3BSE042244R3 Keypad Membrane is 5.7-inch.

    Common misspellings:

    PP86A 3BSE042244R3
    PP826A 3BSE04244R3
    PP862A 3BSE042244R3
    PP826A 3BSE402244R3
    PP826A 33BSE042244R3
