TOPRE0700WD Touch Membrane Protective Film Replacement
M2I TOPRE Series TOPRE0700WD Touch Digitizer Glass Front Overlay Replacement
Screen calibration steps of H TOP Series TOPRE0700WD Front Overlay Touch Panel
1. Turn the power of HTOP Module off.
2. When the power of TOP Module is on, keep the lower part of the screen is touched.
3. When the TOPRE0700WD Protective Film HMI Panel screen is turned white color, remove your hand from the screen.
4. Then the screen display "Touch any point for Calibration" and the number is counted down.
5. Touch anywhere on the TOPRE0700WD HMI Touch Glass screen Front Overlay before changing this number to "0".
6. Along with the message of Calibration Mode, touch the black square is indicated in the middle of the screen.
Continuously touch the TOPRE0700WD Protective Film Touch Membrane upper left, upper right, lower left and lower right part's black square. When completed, the calibration is completed together with the message of Data Saving.
Specification and exchanging on battery
Turn off the TOPRE0700WD Touch Digitizer Glass Protective Film product by using a screwdriver, open the battery case of product and exchange the battery. After exchange of battery, please do assemble the M2I TOPRE0700WD Front Overlay Touch Screen Glass case again. Because rechargeable battery is built in, the internal memory is backed up when the battery is exchanged.
Specifications:
The table below describes the parameters of the M2I TOPRE0700WD Touchscreen Front Overlay HMI Parts.
| Brand: | M2I |
| Operation Temperature: | 0°C ~ +50°C |
| Part Number: | TOPRE0700WD |
| Display Type: | TFT Color |
| Display Color: | 65536 Color |
| Operating Humidity: | 0°C ~ +90°C |
| Storage Temperature: | -10°C ~ +60°C |
| Warranty: | 365 Days |
| Lifespan: | More Than 1 Million Touches |
| Environment: | Free From Corrosive Gases |
Related M2I HMI Part No. :
| M2I HMI | Description | Inventory status |
| HTOP05TQ-SD | M2I H Top Series Touch Screen Film Front Overlay Replacement | In Stock |
| HTOP05TQ-SD2 | M2I H Top Series Protective Film HMI Panel Glass Repair | Available Now |
| HTOP05TQ-SD-W | M2I H Top Series Front Overlay Touch Membrane Replacement | In Stock |
| HTOP05TV-SD | M2I H Top Series HMI Touch Glass Protective Film Repair | Available Now |
| HTOP05TV-SD2 | M2I H Top Series Touch Screen Display Front Overlay Replacement | In Stock |
| HTOP05TV-SD-W | M2I H Top Series Protective Film HMI Panel Screen Repair | Available Now |
| TOPRE0700WD | M2I TOPRE Series Touch Membrane Protective Film Replacement | In Stock |
| TOPRW0500WD | M2I TOPRW Series Touch Digitizer Front Overlay Replacement | Available Now |
| TOPRW0700WD | M2I TOPRW Series Front Overlay MMI Panel Screen Repair | In Stock |
| TOPRW1000WD | M2I TOPRW Series Protective Film Touch Digitizer Glass Replacement | Available Now |
| M2I HMI | Description | Inventory status |
M2I TOPRE Series HMI Manuals PDF Download:
FAQ:
Question: What are the environment specifications of TOPRE0700WD Front Overlay Touch Screen Display?
Answer:
Question: What is M2I TOPRE Series TOPRE0700WD Touch Screen and Protective Film HMI parts price?
Answer: Submit a fast quote, send VICPAS an email for best price.
Common misspellings:
TORE0700WDTOPRE1700WD
TOPRE070WD
TOPR0E0700WD
TTOPRE0700WD
