B&R 5MP050.0653-04 Touch Panel Membrane Keypad

B&R 5MP050.0653-04 Touch Panel Membrane Keypad

B&R 5MP050.0653-04 Touch Panel Membrane Keypad
B&R 5MP050.0653-04 Touch Panel Membrane KeypadB&R 5MP050.0653-04 Touch Panel Membrane KeypadB&R 5MP050.0653-04 Touch Panel Membrane KeypadB&R 5MP050.0653-04 Touch Panel Membrane KeypadB&R 5MP050.0653-04 Touch Panel Membrane Keypad
CategoriesMobile Panel
BrandVICPAS
Model5MP050.0653-04
BrandB&R
Size6.5 inch
ModelB&R Mobile Panel 50 5MP050.0653-04
ShippingDHL/FedEx/UPS/TNT/EMS/Aramex /DPEX
Warranty1 Year VICPAS Warranty
Terms of PaymentWestern Union, T/T, PayPal, T/T ,Credit Card, Western Union
Update TimeNov 7,2024
Detail Information

B&R Mobile Panel 50 5MP050.0653-04 Membrane Keypad Touch Screen Glass Repair

Order each part separately is available

Mobile Panel 50 5MP050.0653-04 Touch Digitizer Membrane Keypad Switch

Control and display panel
• Membrane keys with mechanical pressure point
• 4 (on MP40) or 7 (on MP50) LED status indicators
• Buzzer


An MP100/200 can be connected to the system in place of an MP40/50. The attachment cables feature the same circular connectors allowing for simple exchange by removing and inserting. When connecting an MP40/50, the differences between the devices must be taken into consideration.


5MP050.0653-04 Electronics
• CPU Intel PXA270/416 MHz
• Memory expansion:
° SDRAM: 256 MB
° FLASH: 128 MB



  Contact Best Price


Specifications:

The table below describes the parameters of the 5MP050.0653-04 Mobile Panel 50 Touch Digitizer Membrane Keypad Switch.

Part Number : 5MP050.0653-04
Product Line:Mobile Panel 50
Screen diagonal6.5 in
Warranty: 365 Days Warranty
Input Power24 VDC
Display Type:TFT color
Mounting position: Vertical
Input Type: Keypad
Serial interface Type:RS232
Storage -20 to 70°C


Related B&R Series Part No. :

B&R Mobile Panel 50 Description Inventory status
5MP050.0653-01 B&R Mobile Panel 50 Touch Screen Panel Glass Operator Keyboard In Stock
5MP050.0653-02 Mobile Panel 50 Touch Panel Glass Keyboard Membrane Replacement Available Now
5MP050.0653-03 B&R Mobile Panel 50 Touch Screen Panel Switch Membrane Repair In Stock
5MP050.0653-04 B and R Mobile Panel 50 Touch Digitizer Membrane Switch Replacement Available Now
5MP050.0653-K01 Mobile Panel 50 HMI Touch Screen Organizer Switch Membrane Available Now
5MP050.0653-K03 Mobile Panel 50 Touch Panel Keyboard Membrane Repair In Stock
B and R MP50 Description Inventory status

B&R Mobile Panel 50 Manuals PDF Download:

  • B&R Mobile Panel 40/50 User's Manual
  • Mobile Panel 40/50 Product Datasheet

  • FAQ:

    Question:What is Image Persistence of 5MP050.0653-04?

    Answer: Image persistence refers to the "burning in" of a static image on a display after being displayed for a long time. It does not only occur with static images, however. Image persistence is also referred to in the technical literature as screen burn-in, image retention, memory effect, memory sticking or ghost image.
    There are 2 different types:
    • Area type: This type can be seen in a dark gray image. The effect disappears if the display is switched off for a long time.
    • Line type: This can result in permanent damage.


    Question:How can 5MP050.0653-04 image persistence be reduced?

    Answer:
    • Switch continuously between static and dynamic images.
    • Prevent excessive differences in brightness between foreground and background elements.
    • Use colors with similar brightness.
    • Use complementary colors for subsequent images.
    • Use screensavers.


    Common misspellings:

    MP050.0653-04

    5MP50.0653-04

    5MP050.6053-04

    5MPO50.0653-04

    5MP050.00653-04
