MPCST11NDJ00T Magelis Front Overlay Touch Membrane

MPCST11NDJ00T Magelis Front Overlay Touch Membrane

MPCST11NDJ00T Magelis Front Overlay Touch Membrane
MPCST11NDJ00T Magelis Front Overlay Touch MembraneMPCST11NDJ00T Magelis Front Overlay Touch Membrane
CategoriesMagelis Industrial PC
BrandVICPAS
ModelMPCST11NDJ00T
Touch screen panel typeResistance touch screen
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, T/T, PayPal, Credit Card
Download DOCpdf icondoc iconxls iconrar icon
Update TimeMar 28,2024
Detail Information

Schneider Magelis HMI MPCST11NDJ00T Touch Screen Monitor Protective Film Repair Part


Schneider Magelis HMI MPCST11NDJ00T Touch Screen Monitor Protective Film Repair Kit

For cabinet installation, it is necessary for the correct sized opening to be cut in the installation MPCST11NDJ00T Front overlay touch panel. The installation gasket and installation fasteners are required when installing the Smart MPCST11NDJ00T Touch screen glass protective film unit. When install the Schneider Magelis Smart MPCST11NDJ00T touch digiziter glass from overlay terminal, we should note that:
 Ensure the thickness of the installation panel is from 1.6 to 10 mm (0.06 to 0.39 in).
 All panel surfaces used should be strengthened. Due consideration should be given to the product’s weight, especially if high levels of vibration are expected and the product’s installation surface can move. Metal reinforcing strips can be attached to the inside of the panel near the panel cut-out, to increase the strength of the panel.
 Ensure all installation tolerances are maintained.


VICPAS supply MPCST11NDJ00T Magelis Schneider Touch screen panel glass and protective film with 365 Days warranty and support Urgent Worldwide Shipping.





Specifications:

The table below describes the parameters of the MPCST11NDJ00T Magelis Schneider Front Overlay Touch Screen.

Part Number: MPCST11NDJ00T
Display Type: LCD TFT
Screen Diagonal: 8.4 in
Warranty: 365 Days
Product Line: Magelis Smart Series
Terminal Type: Touchscreen Display
Operating Temp.: 0...50 °C
Storage Temp.: -20...60 °C
Display Resolution: 800 x 600 pixels SVGA
Operating System: Windows XPe SP2


Related Magelis Schneider Smart Series Part No. :

Magelis Smart Description Inventory status
MPCKT52NAX00B Schneider Magelis Smart Touch Screen Protective Film Repair In Stock
MPCST11NDJ00T Magelis Smart Schneider Touch Panel Protective Film Replacement Available Now
MPCST52NAJ20H Schneider Magelis Smart Touchscreen Protective Film Repair In Stock
MPCST52NDJ00T Magelis Smart Schneider HMI Touch Screen Glass Protective Film Available Now
MPCST52NDJ10T Schneider Magelis Smart Touch Screen Panel Front Overlay Repair In Stock
MPCST52NDJ10R Schneider Magelis Smart Front Overlay Touch Membrane In Stock
MPCST21NDJ20T Schneider Magelis Smart HMI Touch Glass Front Overlay Repair In Stock
MPCST21NAJ20T Schneider Magelis Smart Touch Digitizer Glass Overlay Repair Available Now
MPCST52NAJ20T Schneider Magelis Smart HMI Panel Glass Protective Film Available Now
MPCST11NAJ00T Magelis Smart Touch Screen Monitor Front Overlay Replacement In Stock
MPCST11NAJ00H Schneider Magelis Smart MMI Touch Screen Front Overlay In Stock
MPCST52NAN20N Schneider Magelis Smart HMI Touch Screen Protective Film In Stock
Schneider Magelis Description Inventory status


Schneider Magelis Smart HMI Manuals PDF Download:

  • Magelis Industrial PC and Display Catalog
  • Schneider Magelis PC Panel Datasheet
  • Magelis Smart 8.4 inch User Manual
  • Schneider MPCST11NDJ00T Product Datasheet
  • Schneider Electric Human Machine Interfaces Guide
  • The Schneider Magelis® Family of HMI Products

  • FAQ:

    Question: How to Wire the Schneider Magelis Smart MPCST11NDJ00T Terminal Block?

    Answer: When wiring and connecting the wires, be sure to follow the procedures given below:
    1. Remove all power from the Smart 8.4" and confirm that the DC power supply has been disconnected from its power source.
    2. Connect the power cord to the terminal block as shown below:
    How to Wire the Schneider Magelis Smart MPCST11NDJ00T Terminal Block?
    3. Place the terminal block in the power block and tighten the screws. The recommended torque to tighten these screws is 0.5 to 0.6 N•m (4.5 to 5.3 lb-in):
    How to Wire the Schneider Magelis Smart MPCST11NDJ00T Terminal Block?
    NOTE: The 24 Vdc power supply inside the DC-powered Smart units is protected by an 8 A fuse. This fuse is located inside the power supply and cannot be accessed or replaced by the user.


    Question: What is the size of MPCST11NDJ00T Protective Film HMI Panel Glass?

    Answer: The Schneider Terminal MPCST11NDJ00T Touch Screen Monitor Front Overlay is 8.4-inch.
