2711P-B7C22A9P-A Panelview Plus 7 Touch Screen Panel

2711P-B7C22A9P-A Panelview Plus 7 Touch Screen Panel

2711P-B7C22A9P-A Panelview Plus 7 Touch Screen Panel
2711P-B7C22A9P-A Panelview Plus 7 Touch Screen Panel2711P-B7C22A9P-A Panelview Plus 7 Touch Screen Panel2711P-B7C22A9P-A Panelview Plus 7 Touch Screen Panel2711P-B7C22A9P-A Panelview Plus 7 Touch Screen Panel2711P-B7C22A9P-A Panelview Plus 7 Touch Screen Panel
CategoriesPanelView Plus 7 Performance
BrandVICPAS
Model2711P-B7C22A9P-A
Warranty365 Days
BrandRockwell Automation Allen Bradley
Product LinePanelview Plus 7
SupplyPanelview Plus 7 Keypad Keyboard
Size6.5 inch
model2711P-B7C22A9P-A
PartsTouchscreen Panel Glass Membrane Keypad LCD
Terms of PaymentWestern Union, MoneyGram, T/T, Paypal, PayPal, Credit Card
Update TimeNov 5,2024
Detail Information

2711P-B7C22A9P-A Panelview Plus 7 Touch Screen Panel, Membrane Keypad Keyboard, and LCD Display Repair Replacement

Order each part separately is available

2711P-B7C22A9P-A Panelview Plus 7 Keypad Membrane Touch Screen Panel Repair Replacement


All Allen Bradley PanelView Plus 7 performance terminals 2711P-B7C22A9P-A have a color display with a touch screen, or touch screen and keypad, for operator control.
• Analog resistive touch screens provide accurate and durable touch control for industrial applications.
• Keypad models are similar except for the number of function keys to the left and right of the display. Larger models have more keys.


The terminal 2711P-B7C22A9P-A can perform one of three actions at startup:
• Launch a FactoryTalk View Machine Edition HMI application.
• Launch FactoryTalk View Machine Edition Station in Configuration mode. This mode lets you configure terminal settings and start-up options, load applications to run, and enable or disable desktop access.
• Launch the Windows desktop.


The PanelView Plus 7 Performance terminals 2711P-B7C22A9P-A use an EtherNet/IP embedded switch. These terminals communicate with ControlLogix and CompactLogix controllers over an Ethernet connection with DLR, linear, or star network topologies. The terminals can reside on EtherNet/IP networks that run integrated motion and CIP Sync™ applications without affecting performance. The terminal is not a consumer or producer of CIP Sync or motion packets.


VICPAS supply panelview Plus 7 2711P-B7C22A9P-A HMI Touch Screen, Front Overlay, and LCD display Screen. All of them with VICPAS 365 days warranty and support Urgent Worldwide Shipping.



  Contact Best Price


Specifications:

The table below describes the parameters of the Panelview Plus 7 2711P-B7C22A9P-A Operator Panel Parts

Part Number : 2711P-B7C22A9P-A
Display Size: 6.5 inches
Display ColorAmber
Warranty: 365 days Warranty
Product Line:Panelview Plus 7
Input Type:Membrane Keypad
Mounting position: vertical
Communication: Ethernet and RS-232
Communication:ControlNet
Software FactoryTalk


Related Allen Bradley Panelview Plus 7 Terminals Part No. :

PanelView Plus 7 HMI Description Inventory status
2711P-B7C22A9P PanelView Plus 7 Membrane Keypad Touch Screen Panel Glass LCD Display In Stock
2711P-B7C22A9P-A PanelView Plus 7 Membrane Keyboard Touch Panel Glass LCD Display Screen Available Now
2711P-B7C22A9P-B Allen Bradley Panel Plus 7 Keypad Touch Screen Panel LCD Display In Stock
2711P-B7C22D9P Allen Bradley Panel View Plus 7 Keypad Touch Screen LCD Display In Stock
2711P-B7C22D9P-A PanelView Plus 7 Membrane Keypad Touchscreen LCD Display In Stock
2711P-B7C22D9P-B PanelView Plus 7 Touch Panel Membrane Keyboard Keypad LCD Display Screen In Stock
2711P-B10C22A9P PanelView Plus 7 Membrane Keyboard HMI Touch Screen LCD Display Available Now
2711P-B10C22A9P-A Allen Bradley PanelView Plus 7 Keypad Touch Screen LCD Display Replacement In Stock
2711P-B10C22A9P-B PanelView Plus 7 Touchscreen Membrane Operator Panel Keypad LCD Display Available Now
2711P-B10C22D9P Allen Bradley Panel View Plus 7 HMI Panel Glass Keypad LCD Screen In Stock
2711P-B10C22D9P-A Allen Bradley Panel View Plus 7 Keyboard Keypad Touch Screen LCD Display In Stock
2711P-B10C22D9P-B PanelView Plus 7 Touch Screen Glass Membrane Keypad Switch LCD Display In Stock
2711P-B15C22A9P PanelView Plus 7 Touch Screen Monitor Keyboard Keypad LCD Display Screen Available Now
2711P-B15C22A9P-A Allen Bradley PanelView Plus 7 Panel Glass Membrane Keyboard LCD Display In Stock
2711P-B15C22A9P-B PanelView Plus 7 Membrane Keyboard HMI Touch Screen LCD Display Available Now
2711P-B15C22D9P PanelView Plus 7 Membrane Keyboard HMI Touch Screen LCD Display Available Now
2711P-B15C22D9P-A Allen Bradley PanelView Plus 7 Keypad Touch Screen LCD Screen Replacement In Stock
2711P-B15C22D9P-B PanelView Plus 7 Touchscreen Membrane Operator Panel Keypad LCD Display Available Now
2711P-B15C22D9PK Allen Bradley Panel View Plus 7 HMI Panel Glass Keypad LCD Display In Stock
AB PanelView Plus 7 Description Inventory status

AB Panelview Plus 7 Manuals PDF Download:

  • Visualization Solutions PanelView Terminals and Industrial Computers
  • Allen Bradley PanelView Plus 7 Performance Terminals Technical Data
  • AB PanelView Plus 7 2711P-B7C22A9P-A Performance Terminals User Manuals
  • PanelView Plus 7 Operator Interface Standard and Performance


  • FAQ:

    Question: How to enter characters in the display area above the 2711P-B7C22A9P-A keyboard?

    Answer:
    1. Select a character on the keyboard.
    • On a touch screen terminal, touch a key.
    • On a keypad terminal, press the arrow keys to navigate to a key.
    2. Press Select to copy the character to the display area.
    3. Press Enter when done to exit the keyboard.


    Question: How to enable Allen Bradley Plus 7 Performance Terminals desktop access?

    Answer:
    1. Press Terminal Settings, then choose Desktop Access Setup.
    2. To select Allow, press Desktop Access. The Enter Password dialog box opens. Each time that you change desktop access from disallow to allow, you must enter a password. The default password is ‘password’.
    3. To type the password, press Password.
    4. Press Enter.
    5. To return to Desktop Access Management, press Enter again.
    6. Press OK to exit Desktop Access Management, then Close to exit terminal settings and return to the FactoryTalk View ME Station dialog box.
    7. To access the desktop, press Exit. When desktop access is enabled, you are not required to enter a password.


    Question: What are the tips of configuring the 2711P-B7C22A9P-A Ethernet ports of the terminal?

    Answer:
    1. Press Terminal Settings, then choose Networks and Communications>Network Connections>Network Adapters.
    2. To access the Ethernet link settings, press Settings.
    3. To enable or disable the ports that you want to use for your network configuration, press Ethernet Link1 and Ethernet Link2.


    Question: How to connect the operator terminal 2711P-B7C22A9P-A to an AC power source?

    Answer:
    1. Verify that the wiring is not connected to a power source.
    2. Strip 7 mm (0.28 in.) of insulation from the ends of the wire.
    How to connect the operator terminal 2711P-B7C22A9P-A to an AC power source?
    3. Secure the AC power wires to the marked terminals (L1 and L2N) on the terminal block.
    How to connect the operator terminal 2711P-B7C22A9P-A to an AC power source?
    4. Secure the protective earth ground wire to the marked terminal on the terminal block. The protective earth terminal must be connected to a low-impedance earth ground.
    How to connect the operator terminal 2711P-B7C22A9P-A to an AC power source?
    5. Apply power to the operator terminal.
