B&R PP500 5PP5:463148.001-00 Front Overlay Touch Screen

B&R PP500 5PP5:463148.001-00 Front Overlay Touch Screen

B&R PP500 5PP5:463148.001-00 Front Overlay Touch Screen
B&R PP500 5PP5:463148.001-00 Front Overlay Touch ScreenB&R PP500 5PP5:463148.001-00 Front Overlay Touch ScreenB&R PP500 5PP5:463148.001-00 Front Overlay Touch ScreenB&R PP500 5PP5:463148.001-00 Front Overlay Touch ScreenB&R PP500 5PP5:463148.001-00 Front Overlay Touch Screen
CategoriesPower Panel 500
BrandVICPAS
Model5PP5:463148.001-00
BrandB&R
Size5.7 inch
Warranty1 Year VICPAS Warranty
ModelB&R Power Panel 500 5PP5:463148.001-00
ShippingDHL/FedEx/UPS/TNT/EMS/Aramex /DPEX
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, T/T, PayPal, Credit Card
Download DOC
Update Time2022/5/26
Detail Information

B&R Power Panel 500 5PP5:463148.001-00 Front Overlay Touch Panel Repair Replacement

Order each part separately is available

Power Panel 500 5PP5:463148.001-00 Protective Film Touchscreen Glass

Powered by Intel® Atom™ architecture, the new Power Panel 500 series delivers performance previously only possible with industrial PCs. The Intel® Atom™ Z5xx processors equipped in the Power Panel 500 have enough power to handle even the most challenging applications. There is also plenty of room for RAM – up to 2 GB. This extensive product range includes panels ranging from 5.7" VGA to 15" XGA displays with intuitive touch screen and function keys. Gigabit Ethernet ensures high-speed communication over the plant network. Additional fieldbus interfaces or another gigabit Ethernet interface can also be added if needed. When designing the Power Panel 500, developers focused specifically on minimizing installation depth so that these systems can be used in extremely tight spaces.


B&R Power Panel 500 5PP5:463148.001-00 Features:
• Intel® Atom™ Z510, Z520 or Z530 processor
• Up to 2 GB SDRAM
• 2x USB 2.0 (5.7" and 7" devices), 3x USB 2.0 (10.4", 12.1" and 15" devices)
• 1x RS232
• 1x Ethernet 10/100/1000 Mbit/s
• Optional interface and I/O boards
• 1 CompactFlash slot (type I)
• 24 VDC supply voltage
• Operation without a fan or heat sink
• BIOS (Insyde)
• Real-time clock (RTC, battery-backed)



  Contact Best Price


Specifications:

The table below describes the parameters of the 5PP5:463148.001-00 Power Panel 500 Touchscreen Panel Front Overlay.

Part Number : 5PP5:463148.001-00
Product Line:Power Panel 500
Screen diagonal5.7 in
Warranty: 365 Days Warranty
Input Power24 VDC
Display Type:TFT color
Mounting position: Vertical
Input Type: Touchscreen
Serial interface Type:RS232
Storage -20 to 70°C


Related Power Panel 500 Series Part No. :

B&R Power Panel 500 Description Inventory status
5PP520-1505-B00 B&R Power Panel 500 Touch Screen Panel Glass HMI Repair In Stock
5PP520-1505-B10 Power Panel 500 B and R Touch Panel Glass Replacement Available Now
5PP520-1505-B50 B&R Power Panel 500 Touch Screen Panel Repair In Stock
5PP520-1505-B55 B and R Power Panel 500 Touch Digitizer Replacement In Stock
5PP520-1505-B60 Power Panel 500 B&R HMI Touch Screen Organizer In Stock
5PP520-1505-B65 B and R Power Panel 500 Touch Panel Glass Repair In Stock
5PP580-1505-00 Power Panel 500 B&R HMI Touch Screen Organizer Available Now
5PP580-1505-K01 Power Panel 500 B&R Touch Screen Monitor Replacement In Stock
5PP581-1505-00 B and R Power Panel 500 Touch Screen Hmi Monitor Available Now
5PP5:463148.001-00 B&R Power Panel 500 Touch Panel Glass Organizer Protective Film In Stock
5PP5:206114.002-00 B&R Power Panel 500 HMI Touch Screen Panel Glass Repair In Stock
B and R PP500 Description Inventory status

B&R Power Panel 500 Manuals PDF Download:

  • B&R Power Panel 500 User's Manual

  • FAQ:

    Question: How can the B&R Power Panel 500 service life of the backlight be extended?

    Answer:
    • By setting the display brightness to the lowest value that is still comfortable for the eyes
    • By using dark images
    • By reducing the brightness by 50%, which can result in an approximately 50% increase in the half-brightness time


    Question: What is the procedure of replacing the B and R PP500 5PP5:463148.001-00 battery?

    Answer:
    • Disconnect the power supply to the B&R Industrial PC.
    • Touch the housing or ground connection in order to discharge any electrostatic charge from your body.
    • Remove the cover from the battery compartment and carefully pull out the battery using the removal strip.
    What is the procedure of replacing the B and R PP500 5PP5:463148.001-00 battery?
    • The battery should not be held by its edges. Insulated tweezers may also be used to insert the battery.
    What is the procedure of replacing the B and R PP500 5PP5:463148.001-00 battery?
    • Insert the new battery with the correct polarity.
    What is the procedure of replacing the B and R PP500 5PP5:463148.001-00 battery?
    • To make the next battery replacement easier, be sure the removal strip is in place when inserting the battery.
    • Reconnect the power supply to the B&R Industrial PC (plug in the power cable).
    • Reset the date and time in BIOS.
    What is the procedure of replacing the B and R PP500 5PP5:463148.001-00 battery?

    Common misspellings:

    5PP5:46314B.001-00

    5PP5:463148.001-OO

    5PP5:463148.00l-00

    5PP5:463l48.001-00
