PanelView 5500 2715-T12WD Touch Overlay Display Repair

PanelView 5500 2715-T12WD Touch Overlay Display Repair

PanelView 5500 2715-T12WD Touch Overlay Display Repair
PanelView 5500 2715-T12WD Touch Overlay Display RepairPanelView 5500 2715-T12WD Touch Overlay Display RepairPanelView 5500 2715-T12WD Touch Overlay Display RepairPanelView 5500 2715-T12WD Touch Overlay Display Repair
CategoriesPanelView 5500
BrandVICPAS
Model2715-T12WD
Shipping2-3 workdays
Product LineAllen-Bradley PanelView 5500 Repair Kit
SupplyLCD Display, Touch Panel Glass and Overlay
Size12.1-inch
Touch PointsSingle-touch
Material Appliedfilm+Glass+tail
Warranty365 Days
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, MoneyGram, T/T, Paypal, PayPal, Credit Card
Update TimeMar 29,2024
Detail Information

Allen-Bradley PanelView 5500 HMI 2715-T12WD Protective Film Touch Screen Panel LCD Display Replacement

Order each part separately is available

Allen-Bradley PanelView 5500 HMI 2715-T12WD Protective Film Touchscreen LCD Display Replacement

The 2715-T12WD Touch Digitizer Monitor Protective Film LCD Display Panel terminals have a color display with a touch screen and navigation key, or a touch screen, navigation key, and keypad for operator control.

• Analog, resistive, touch screens provide accurate, durable touch with excellent reliability for control of industrial applications.

• Keypad models are similar except for the number of function keys to the left (L#) and right (R#) of the display. Larger models have more keys.


The PanelView 5500 2715-T12WD Touch Screen monitor Front Overlay LCD Display Screen terminals include these features and capabilities:

• Tightly integrated control and design environment allows information to be shared between the 2715-T12WD Touch Overlay LCD Screen Display terminal and the Logix platforms.

• The Studio 5000® environment provides one point of access for both View Designer and Logix Designer applications.

• Connection to one ControlLogix 5570 or CompactLogix L1, L2, or L3 controller with revision 27 firmware or later.


VICPAS supply Allen Bradley PanelView 5500 HMI 2715-T12WD HMI Touch Panel Front Overlay and LCD Screen Display with 365 Days warranty and support Urgent Worldwide Shipping.






Specifications:

The table below describes the parameters of the 2715-T12WD PanelView 5500 Parts.

Part Number: 2715-T12WD
Display Size: 12.1 inches widescreen
Backlight: LED, non-replaceable
Brightness: 300 cd/m2 (Nits)
Status Indicators: STS (green), ERR (red)
Color Depth: 18-bit color graphics
Display Resolution: 1280 x 800 WXGA, 16:10
Relative Humidity: 5…95% without condensation
Operating Temperature: 0°C - 55°C
Storage Temperature: - 25°C - 70°C


Related Allen Bradley PanelView 5500 Terminals Part No. :

PanelView 5500 Description Inventory status
2715-B10CA 2715-B10CA PanelView 5500 Keyboard Touch Display Repair In Stock
2715-B10CA-B 2715-B10CA-B Keyboard Touch LCD Display Replacement Available Now
2715-B10CD PanelView 5500 2715-B10CD Touch Keypad Display Repair In Stock
2715-B10CD-B 2715-B10CD-B Display Keyboard Glass Repair Replacement Available Now
2715-T10CA PanelView 5500 2715-T10CA Panel Glass Protective Film In Stock
2715-T10CA-B 2715-T10CA-B PanelView 5500 Film Display Touch Reapir In Stock
2715-T10CD 2715-T10CD PanelView 5500 Overlay Panel Glass Repair In Stock
2715-T10CD-B PanelView 5500 2715-T10CD-B Front Overlay Touch Repair Available Now
2715-T12WA 2715-T12WA 12.1'' PanelView 5500 HMI Touch Panel Film Available Now
2715-T12WA-B PanelView 5500 2715-T12WA-B Panel Glass Film Repair kit In Stock
2715-T12WD PanelView 5500 2715-T12WD Touch Overlay Display Repair In Stock
2715-T12WD-B 2715-T12WD-B PanelView 5500 Panel Glass Overlay Display In Stock
PanelView 5500 HMI Description Inventory status

PanelView 5500 HMI Manuals PDF Download:

  • Allen-Bradley PanelView 5500 Terminals User Manual
  • Allen-Bradley PanelView Standard Terminal Specifications
  • PanelView 5500 Specifications Technical Data

  • FAQ:

    Question: How to remove the PanelView 5500 HMI 2715-T12WD Touchscreen Front Overlay LCD Display terminal block?

    Answer:

  • 1. Loosen the two screws that secure the terminal block.
  • 2. Gently pull the terminal block away from the connector. To install the 2715-T12WD HMI Touch Panel Protective Film LCD Screen Display terminal block, follow these steps.
  • ①Reattach the terminal block to the connector until seated.
  • ②Tighten the two screws that secure the 2715-T12WD Touch Overlay LCD Display terminal block to the connector.
    How to remove the terminal block?

  • Question: What other tasks you must do?

    Answer:

    • Configure the Ethernet settings and update the firmware of the PanelView 5500 HMI 2715-T12WD Touch Panel Glass Front Overlay LCD Display terminal.

    • Create an application by using the Studio 5000 View Designer® application.

    • Create a project for the controller by using the Studio 5000 Logix Designer® application.
