PanelView 5500 2715-T7CA Touch Panel Front Film Repair

PanelView 5500 2715-T7CA Touch Panel Front Film Repair

PanelView 5500 2715-T7CA Touch Panel Front Film Repair
PanelView 5500 2715-T7CA Touch Panel Front Film RepairPanelView 5500 2715-T7CA Touch Panel Front Film RepairPanelView 5500 2715-T7CA Touch Panel Front Film RepairPanelView 5500 2715-T7CA Touch Panel Front Film Repair
CategoriesPanelView 5500
BrandVICPAS
Model2715-T7CA
Warranty365 Days
Product LineAllen-Bradley PanelView 5500 Repair Kit
TypesTouch Screen Monitor Protective Film
Shipping2-3 workdays
Size7 inches
FPC10 wires
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, MoneyGram, T/T, Paypal, PayPal, Credit Card
Update TimeJul 22,2024
Detail Information

Allen-Bradley PanelView 5500 HMI 2715-T7CA Front Overlay Resistive Touch Screen Repair

Order each part separately is available

Allen-Bradley PanelView 5500 HMI 2715-T7CA Protective Film Touchscreen Replacement


When using PanelView 5500 HMI 2715-T7CA Protective Film Touch Digitizer Monitor LCD Display terminal outdoors, you must follow the recommendations outlined below to maximize the field life of the front bezel and display:

• Add UV protection and shielding (sun shade or sun visor)

• Manage terminal temperature

• Install a protective overlay

• Consider terminal orientation

• Select a proper enclosure


During runtime, the PanelView™ 5500 terminal runs HMI projects. A project is configured and downloaded to your 2715-T7CA Overlay HMI Touch Panel LCD Display Panel terminal from the View Designer application. The project launches each time the terminal restarts. The 2715-T7CA Protective Film Resistive Touch Screen LCD Display terminal exchanges data values with the controller, animates the displayed data, and responds when you press keys or touch a screen or element on a screen. During runtime, you can perform these tasks:

• Navigate screens and their graphic elements

• View and manage alarms

• View and perform operations on a trend chart

• Display error information

• Configure terminal settings and view diagnostic information


VICPAS supply Allen Bradley PanelView 5500 HMI 2715-T7CA Resistive Touch Panel Front Overlay and LCD Display Panel with 365 Days warranty and support Urgent Worldwide Shipping.






Specifications:

The table below describes the parameters of the 2715-T7CA PanelView 5500 Parts.

Part Number: 2715-T7CA
Display Type: Color TFT LCD
View Area(W x H): 132 x 99 mm
Operating Temperature: 0°C - 55°C
Storage Temperature: - 25°C - 70°C
Color Depth: 18-bit color graphics
Display Resolution: 640 x 480 VGA, 4:3
Backlight: LED, non-replaceable
Input Voltage: 100…240V AC
Status Indicators: STS (green), ERR (red)


Related Allen Bradley PanelView 5500 Terminals Part No. :

PanelView 5500 Description Inventory status
2715-T7CA PanelView 5500 2715-T7CA Touch Panel Front Film Repair In Stock
2715-T7CA-B PanelView 5500 2715-T7CA-B Panel Glass Film Repair kit Available Now
2715-T7CD 2715-T7CD PanelView 5500 Touch Digitizer Overlay Repair In Stock
2715-T7CD-B 2715-T7CD-B PanelView 5500 Touch Overlay Replacement Available Now
2715-B7CA PanelView 5500 2715-B7CA Glass Display Keypad Repair In Stock
2715-B7CA-B PanelView 5500 2715-B7CA-B Keyboard Display Touch Glass In Stock
2715-B7CD 2715-B7CD PanelView 5500 Keypad LCD Display Touch Repair In Stock
2715-B7CD-B 2715-B7CD-B PanelView 5500 Touch Digitizer Keyboard Kit Available Now
2715-T9WA 2715-T9WA PanelView 5500 Front Overlay Glass Repair In Stock
2715-T9WA-B 2715-T9WA-B PanelView 5500 Panel Glass Film Repair Kit Available Now
2715-T9WD PanelView 5500 2715-T9WD Touch Overlay Replacement In Stock
2715-T9WD-B PanelView 5500 2715-T9WD-B Touch Glass Film Replacement In Stock
PanelView 5500 HMI Description Inventory status

PanelView 5500 HMI Manuals PDF Download:

  • Allen-Bradley PanelView 5500 Terminals User Manual
  • Allen-Bradley PanelView Standard Terminal Specifications
  • PanelView 5500 Specifications Technical Data

  • FAQ:

    Question: How to connect the PanelView 5500 HMI 2715-T7CA Protective Film Touch Screen Monitor LCD Display operator terminal to an AC power source?

    Answer:

    1. Verify that the wiring is not connected to a power source.

    2. Strip 7 mm (0.28 in.) of insulation from the ends of the wire.

    How to connect the operator terminal to an AC power source?

    3. Secure the AC power wires to the marked terminals (L1 and L2N) on the terminal block.

    How to connect the operator terminal to an AC power source?

    4. Secure the protective earth ground wire to the marked terminal on the terminal block. The protective earth terminal must be connected to a low-impedance earth ground.

    5. Apply power to the 2715-T7CA Front Overlay Touch Screen Glass LCD Display Panel operator terminal.


    Question: How to install an SD card in the card slot?

    Answer: The SD card slot is accessible from the inside or back of the panel when the 2715-T7CA Overlay Resistive Touch Screen LCD Screen Display operator terminal is installed.

  • 1. Verify that the SD card is locked or unlocked according to your preference.
  • • If unlocked, the terminal can write data to or read data from the card.
  • • If locked, the terminal can only read data from the card.
  • How to install an SD card in the card slot?
  • 2. Insert the SD card firmly into the slot until you hear a click. When you hear the click, the card has locked into place. To remove the card, push the card in slightly to unlock the SD card so you can remove it from the slot.
  • How to install an SD card in the card slot?
