2715-T9WA-B PanelView 5500 Panel Glass Film Repair Kit

2715-T9WA-B PanelView 5500 Panel Glass Film Repair Kit

2715-T9WA-B PanelView 5500 Panel Glass Film Repair Kit
2715-T9WA-B PanelView 5500 Panel Glass Film Repair Kit2715-T9WA-B PanelView 5500 Panel Glass Film Repair Kit2715-T9WA-B PanelView 5500 Panel Glass Film Repair Kit2715-T9WA-B PanelView 5500 Panel Glass Film Repair Kit
CategoriesPanelView 5500
BrandVICPAS
Model2715-T9WA-B
SupplyResistance touch screen and Overlay
Warranty365 Days
Shipping2-3 workdays
FPC10 wires
Product LineAllen-Bradley PanelView 5500 Repair Kit
Size9-inch
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, MoneyGram, T/T, Paypal, PayPal, Credit Card
Update TimeJul 22,2024
Detail Information

Allen-Bradley PanelView 5500 HMI 2715-T9WA-B Front Overlay Resistive Touch Panel Repair Replacement

Allen-Bradley PanelView 5500 HMI 2715-T9WA-B Front Overlay Touchscreen Replacement

When using PanelView 5500 HMI 2715-T9WA-B Protective Film Touch Panel Glass terminal outdoors, you must follow the recommendations outlined below to maximize the field life of the front bezel and display:

• Add UV protection and shielding (sun shade or sun visor)

• Manage terminal temperature

• Install a protective overlay

• Consider terminal orientation

• Select a proper enclosure


During runtime, the PanelView™ 5500 terminal runs HMI projects. A project is configured and downloaded to your 2715-T9WA-B Overlay HMI Touch Panel terminal from the View Designer application. The project launches each time the terminal restarts. The 2715-T9WA-B Protective Film Resistive Touch Screen terminal exchanges data values with the controller, animates the displayed data, and responds when you press keys or touch a screen or element on a screen. During runtime, you can perform these tasks:

• Navigate screens and their graphic elements

• View and manage alarms

• View and perform operations on a trend chart

• Display error information

• Configure terminal settings and view diagnostic information


VICPAS supply Allen Bradley PanelView 5500 HMI 2715-T9WA-B Resistive Touch Panel and Front Overlay with 365 Days warranty and support Urgent Worldwide Shipping.






Specifications:

The table below describes the parameters of the 2715-T9WA-B PanelView 5500 Parts.

Part Number: 2715-T9WA-B
Relative Humidity: 5…95% without condensation
Operating Temperature: 0°C - 55°C
Storage Temperature: - 25°C - 70°C
Display Size: 9 inches widescreen
Color Depth: 18-bit color graphics
Display Resolution: 800 x 480 WVGA, 5:3
Display Type: Color TFT LCD
Brightness: 300 cd/m2 (Nits)
USB Host Ports (type A): 0.5A at 5V DC


Related Allen Bradley PanelView 5500 Terminals Part No. :

PanelView 5500 Description Inventory status
2715-T7CA PanelView 5500 2715-T7CA Touch Panel Front Film Repair In Stock
2715-T7CA-B PanelView 5500 2715-T7CA-B Panel Glass Film Repair kit Available Now
2715-T7CD 2715-T7CD PanelView 5500 Touch Digitizer Overlay Repair In Stock
2715-T7CD-B 2715-T7CD-B PanelView 5500 Touch Overlay Replacement Available Now
2715-B7CA PanelView 5500 2715-B7CA Glass Display Keypad Repair In Stock
2715-B7CA-B PanelView 5500 2715-B7CA-B Keyboard Display Touch Glass In Stock
2715-B7CD 2715-B7CD PanelView 5500 Keypad LCD Display Touch Repair In Stock
2715-B7CD-B 2715-B7CD-B PanelView 5500 Touch Digitizer Keyboard Kit Available Now
2715-T9WA 2715-T9WA PanelView 5500 Front Overlay Glass Repair In Stock
2715-T9WA-B 2715-T9WA-B PanelView 5500 Panel Glass Film Repair Kit Available Now
2715-T9WD PanelView 5500 2715-T9WD Touch Overlay Replacement In Stock
2715-T9WD-B PanelView 5500 2715-T9WD-B Touch Glass Film Replacement In Stock
PanelView 5500 HMI Description Inventory status

PanelView 5500 HMI Manuals PDF Download:

  • Allen-Bradley PanelView 5500 Terminals User Manual
  • Allen-Bradley PanelView Standard Terminal Specifications
  • PanelView 5500 Specifications Technical Data

  • FAQ:

    Question: How to connect the PanelView 5500 HMI 2715-T9WA-B Protective Film Touch Screen Monitor operator terminal to an AC power source?

    Answer:

    1. Verify that the wiring is not connected to a power source.

    2. Strip 7 mm (0.28 in.) of insulation from the ends of the wire.

    How to connect the operator terminal to an AC power source?

    3. Secure the AC power wires to the marked terminals (L1 and L2N) on the terminal block.

    How to connect the operator terminal to an AC power source?

    4. Secure the protective earth ground wire to the marked terminal on the terminal block. The protective earth terminal must be connected to a low-impedance earth ground.

    5. Apply power to the 2715-T9WA-B Front Overlay Touch Screen Glass operator terminal.


    Question: How to apply the PanelView 5500 HMI 2715-T9WA-B Protective Overlay?

    Answer:

  • 1. Pull the tab from one of the short sides and partially peel the liner away from adhesive layer.
  • Allen-Bradley PanelView 5500 HMI 2715-T9WD Touchscreen Replacement
    Allen-Bradley PanelView 5500 HMI 2715-T9WD Touchscreen Replacement
  • 2. Center the 2715-T9WA-B overlay over the bezel and carefully position the adhesive surface on the terminal. While the protective liner is still covering the rest of the overlay, verify that it is properly centered.
  • 3. Slowly peel off the rest of the liner while using a soft cloth to press the 2715-T9WA-B overlay on the 2715-T9WA-B screen. Make sure that the 2715-T9WA-B overlay lies flat with no bubbles or warps.
  • 4. With a soft cloth or finger, press around the edges of the 2715-T9WA-B overlay to seal it, and remove any air bubbles trapped in the adhesive.

  • Common misspellings:

    275-T9WA-B
    2715-T9A-B
    7215-T9WA-B
    2715-9TWA-B
    2715--T9WA-B
