2715-T9WA PanelView 5500 Front Overlay Glass Repair

2715-T9WA PanelView 5500 Front Overlay Glass Repair

2715-T9WA PanelView 5500 Front Overlay Glass Repair
2715-T9WA PanelView 5500 Front Overlay Glass Repair2715-T9WA PanelView 5500 Front Overlay Glass Repair2715-T9WA PanelView 5500 Front Overlay Glass Repair2715-T9WA PanelView 5500 Front Overlay Glass Repair
CategoriesPanelView 5500
BrandVICPAS
Model2715-T9WA
Warranty365 Days
Product LineAllen-Bradley PanelView 5500 Repair Kit
TypesFront Overlay Touch Screen Panel
Shipping2-3 workdays
Size9 inches
FPC10 wires
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, MoneyGram, T/T, Paypal, PayPal, Credit Card
Update TimeJul 22,2024
Detail Information

Allen-Bradley PanelView 5500 HMI 2715-T9WA Touch Screen Monitor Protective Film Repair Replacement

Allen-Bradley PanelView 5500 HMI 2715-T9WA Touchscreen Front Overlay Replacement

The PanelView Standard 2715-T9WA Resistive Touch Screen Protective Film terminals feature pixel graphics capabilities and functionality in color, grayscale, and monochrome displays. These rugged electronic operator interface solutions are available in a variety of sizes and configurations to meet specific application requirements. All use common development software to simplify programming and improve operator productivity.


The PanelView 5500 HMI 2715-T9WA Touch Screen Glass Front Overlay terminal communicates with PLC and SLC controllers over EtherNet/IP, DeviceNet, ControlNet, DH-485, DH+, and remote I/O networks, or by using serial communication.


Other features supported by the PanelView Standard line include advanced alarm handling, screen security, analog gauges, ATA memory card, universal language support, and online printing for more intuitive operator control.


VICPAS supply Allen Bradley PanelView 5500 2715-T9WA HMI Touch Panel and Front Overlay with 365 Days warranty and support Urgent Worldwide Shipping.






Specifications:

The table below describes the parameters of the 2715-T9WA PanelView 5500 Parts.

Part Number: 2715-T9WA
Input Voltage: 100…240V AC
USB Host Ports (type A): 0.5A at 5V DC
Backlight: LED, non-replaceable
Warranty: 365 Days
View Area(W x H): 196 x 118 mm
Color Depth: 18-bit color graphics (262,144 colors)
Display Resolution: 800 x 480 WVGA, 5:3
Brightness: 300 cd/m2 (Nits)
Display Type: Color TFT LCD


Related Allen Bradley PanelView 5500 Terminals Part No. :

PanelView 5500 Description Inventory status
2715-T7CA PanelView 5500 2715-T7CA Touch Panel Front Film Repair In Stock
2715-T7CA-B PanelView 5500 2715-T7CA-B Panel Glass Film Repair kit Available Now
2715-T7CD 2715-T7CD PanelView 5500 Touch Digitizer Overlay Repair In Stock
2715-T7CD-B 2715-T7CD-B PanelView 5500 Touch Overlay Replacement Available Now
2715-B7CA PanelView 5500 2715-B7CA Glass Display Keypad Repair In Stock
2715-B7CA-B PanelView 5500 2715-B7CA-B Keyboard Display Touch Glass In Stock
2715-B7CD 2715-B7CD PanelView 5500 Keypad LCD Display Touch Repair In Stock
2715-B7CD-B 2715-B7CD-B PanelView 5500 Touch Digitizer Keyboard Kit Available Now
2715-T9WA 2715-T9WA PanelView 5500 Front Overlay Glass Repair In Stock
2715-T9WA-B 2715-T9WA-B PanelView 5500 Panel Glass Film Repair Kit Available Now
2715-T9WD PanelView 5500 2715-T9WD Touch Overlay Replacement In Stock
2715-T9WD-B PanelView 5500 2715-T9WD-B Touch Glass Film Replacement In Stock
PanelView 5500 HMI Description Inventory status

PanelView 5500 HMI Manuals PDF Download:

  • Allen-Bradley PanelView 5500 Terminals User Manual
  • Allen-Bradley PanelView Standard Terminal Specifications
  • PanelView 5500 Specifications Technical Data

  • FAQ:

    Question: What is the size of the 2715-T9WA HMI Touch Panel Glass and Overlay?

    Answer: The 2715-T9WA Touch Screen Panel and Protective Film are 9-inch.


    Question: What is the 2715-T9WA Panelview 5500 Resistive Touch Screen and Protective Film HMI parts price?

    Answer: Submit a fast quote, send VICPAS an email for best price.


    Question: How to replace the battery?

    Answer:

  • 1. Disconnect power from the PanelView 5500 HMI 2715-T9WA Overlay Touch Digitizer Monitor terminal.
  • 2. Loosen the screws that secure the logic module to the back of the display.
  • Allen-Bradley PanelView 5500 HMI 2715-T9WA Protective Film Touchscreen Replacement
  • 3. Carefully lift the logic module away from the display module and turn over to expose the circuit board.
  • 4. Locate the coin-cell battery on the circuit board.
    Allen-Bradley PanelView 5500 HMI 2715-T9WA Protective Film Touchscreen Replacement
  • 5. Remove the battery by lifting on the side of the battery.
  • 6. Insert the new battery with the positive (+) polarity up.
  • 7. Reattach the logic module by aligning the connector on the bottom of the logic module with the connector on the back of the display module.
    Allen-Bradley PanelView 5500 HMI 2715-T7CA-B Protective Film Touchscreen Replacement
  • 8. Push down on the logic module and make sure that it is fully seated.
  • 9. Tighten the screws to a torque of 0.68…0.90 N•m (6…8 lb•in).
