PP877K 3BSE069274R1 Touch Screen Membrane Keypad Repair

PP877K 3BSE069274R1 Touch Screen Membrane Keypad Repair

PP877K 3BSE069274R1 Touch Screen Membrane Keypad Repair
PP877K 3BSE069274R1 Touch Screen Membrane Keypad RepairPP877K 3BSE069274R1 Touch Screen Membrane Keypad RepairPP877K 3BSE069274R1 Touch Screen Membrane Keypad RepairPP877K 3BSE069274R1 Touch Screen Membrane Keypad RepairPP877K 3BSE069274R1 Touch Screen Membrane Keypad Repair
CategoriesPanel 800
BrandVICPAS
ModelPP877K 3BSE069274R1
Warranty365 Days
Product LineHMI Panel 800
SupplyMembrane Switch and Resistive Touch Panel
Shipping2-3 workdays
Size10.4 inches
Part NumberPP877K 3BSE069274R1
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, MoneyGram, T/T, Paypal, PayPal, Credit Card
Download
Update TimeJul 19,2024
Detail Information

HMI Panel 800 PP877K 3BSE069274R1 Membrane Keyboard Keypad Touch Membrane Replacement

Order each part separately is available

PP877K 3BSE069274R1 Membrane Keypad Switch Touch Panel Repair

PP877K 3BSE069274R1 Operator Keyboard Touchscreen Glass Panel 800 Feature:


Easy to use
A fully deployable PP877K 3BSE069274R1 Touch Digitizer Operator Panel Keypad HMI with comprehensive and integrated templates and libraries for every conceivable process. The Panel Builder tool, with familiar Microsoft® Windows® environment along with multiple language support results in remarkably quick, easy and efficient engineering.


Robust and reliable technology
PP877K 3BSE069274R1 Keyboard Membrane Touch Screen Monitor Panel 800 is constructed in a strong yet lightweight die-cast, powder-coated aluminum housing. IP65/IP66 front casing withstands wet, dusty and demanding environments. Operating temperatures ranging between -30℃ to 70℃ with maximum 95% humidity.


Truly open platform
Built on open architecture and technologies that accompany the .NET framework, these panels are capable of multi-brand controller connectivity. A multitude of connection options are available for local communication, expansion, remote access and more.


State-of-the-arts graphics
Vector-based, high-resolution graphics in TFL/LED display, with icon-based interface navigation and control.





Specifications:

The table below describes the parameters of the PP877K 3BSE069274R1 Keypad Membrane Touchscreen HMI Panel 800.

Display Resolution: 800 × 480 pixels
Display Type: TFT LCD
Part Number: PP877K 3BSE069274R1
Size: 10 inches
Warranty: 365 Days
Active Area of Display: 211.2 × 158.4 mm
Backlight Colors: 64 k colors
Backlight Lifetime: 50,000 hours
Touch Material: Polyester on glass, resistive
Screen Brightness: 450 cd/m2


Related HMI Panel 800 Terminals Part No. :

HMI Panel 800 Description Inventory status
PP874 3BSE069271R2 Panel 800 PP874 Front Overlay Touch Membrane In Stock
PP874K 3BSE069273R1 Panel 800 Series PP874K Membrane Keypad Replacement Repair In Stock
PP874M 3BSE069279R1 Panel 800 Series PP874M Touch Digitizer Glass Overlay Repair Available Now
PP875 3BSE092977R1 Panel 800 PP875 HMI Panel Glass Protective Film Replacement Available Now
PP875H 3BSE092983R1 Panel 800 Series PP875H Touch Screen Monitor Front Overlay In Stock
PP875M 3BSE092982R1 Panel 800 Series PP875M Front Overlay MMI Touch Screen In Stock
PP877 3BSE069272R1 Panel 800 Series PP877 HMI Touch Screen Protective Film Available Now
PP877 3BSE069272R2 Panel 800 Series PP877 Protective Film Touchscreen Repair In Stock
PP877K 3BSE069274R1 Panel 800 Series PP877K HMI Membrane Switch Touch Screen Glass Available Now
PP880R 3BSE069295R1 Panel 800 Series PP880R Front Overlay Touch Screen Panel Repair In Stock
PP881 3BSE092978R1 Panel 800 Series PP881 Touch Screen Protective Film Replacement In Stock
PP882 3BSE069275R1 Panel 800 Series PP882 Front Overlay Touch Digitizer Glass Available Now
PP883 3BSE092979R1 Panel 800 PP883 Protective Film HMI Panel Glass Replacement In Stock
Panel 800 Repair Description Inventory status


Panel 800 HMI Manuals PDF Download:

  • 3BSE069459-600 Panel 800 Version 6 PP877 Hardware and Installation
  • 3BSE069461-600 B en Panel 800 Version 6 PP877K Hardware and Installation
  • Panel 800 Version 6 PP874M Hardware and Installation
  • Panel 800 Version 6 PP885M Hardware and Installation
  • Panel 800 Version 6 PP885H Hardware and Installation
  • Panel 800 Version 6 PP880R Hardware and Installation
  • Panel 800 Version 6 PP885R Hardware and Installation
  • Panel 800 Version 6 PP886H Hardware and Installation
  • Compact Product Suite Panel 800 Version 6 PP885 Hardware and Installation

  • FAQ:

    Question: What is the size of the PP877K 3BSE069274R1 Touch Screen Monitor and Switch Membrane?

    Answer: The PP877K 3BSE069274R1 Membrane Keyboard Touch Membrane is 10-inch.


    Question: Grounding the PP877K 3BSE069274R1 Terminal Keypad Touch Pad operator panel

    Solution: PP877K 3BSE069274R1 Touch Panel Switch Membrane Repair
    The mounting clamps of the operator panel do not provide a secure grounding connection between the panel and the device cabinet, see 1 in drawing above.
    1. Connect a wire, that is sized correctly according to local electrical codes, between the quick-connect terminal connector on the operator panel and the chassis of the panel, see 2 in drawing above.
    2. Connect a wire or grounding braid, that is sized correctly according to local electrical codes, between the chassis of the operator panel and the closest grounding point on the door, see 3 in drawing above.
    3. Connect a strong but short grounding braid between the door and the device cabinet, see 4 in drawing above.
    4. Twist the cables onto the 24 V DC feed, see 5 in drawing above.
    2 turns around the ferrite core provide 4 times the suppression of 1 turn.
    3 turns around the ferrite core provide 9 times the suppression of 1 turn.
    A ferrite core suppresses disturbances to the 24 V feed, see 6 in drawing above.
    The grounding wires should be short and the conductor should have a large area.
    A long, thin grounding wire has a very high impedance (resistance) at high frequencies and does not guide disturbances to the ground.
    Multi-wire conductors are better than single wire conductors with the same area.
    A braided conductor wire with the same area is even better. The best is a short, thick grounding braid.

    Common misspellings:

    PP877K 3BSE06924R1
    PP77K 3BSE069274R1
    PP877K 3SBE069274R1
    PP877K 3BSE069Z74R1
    PP8777K 3BSE069274R1
