2711-M3A19L1 PanelView 300 Membrane Keyboard Keypad

2711-M3A19L1 PanelView 300 Membrane Keyboard Keypad

2711-M3A19L1 PanelView 300 Membrane Keyboard Keypad
2711-M3A19L1 PanelView 300 Membrane Keyboard Keypad2711-M3A19L1 PanelView 300 Membrane Keyboard Keypad2711-M3A19L1 PanelView 300 Membrane Keyboard Keypad2711-M3A19L1 PanelView 300 Membrane Keyboard Keypad2711-M3A19L1 PanelView 300 Membrane Keyboard Keypad
CategoriesPanelview 300
BrandVICPAS
Model2711-M3A19L1
BrandAllen Bradley
Warranty6 Months
Product LinePanelView 300
Size3 Inch
SupplyPanelView 300 Membrane Keypad
model2711-M3A18L1
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, T/T, PayPal, T/T ,Credit Card, Western Union
Download
Update TimeJul 19,2024
Detail Information

2711-M3A19L1 PanelView 300 Membrane Keyboard Keypad, LCD Display, Enclosure, Gasket Repair Replacement

Order each part separately is available

 2711-M3A19L1 PanelView 300 Membrane Keyboard Keypad, HMI Case, Gasket, LCD Display Screen Repair Replacement

The 2711-M3A19L1 is an Allen-Bradley PanelView 300 operator terminal. The discontinued 2711-M3A19L1 PanelView 300 is an operator terminal that enables the user to interface with their machine. This HMI has a 3 in. monochrome display. This 2711-M3A19L1 PanelView allows the user to connect using Panelbuilder 32 software and an RS-232 (DH-485) Communication Port (8-Pin Mini-DIN) communication port with a 1761-CBL-PM05 communication cable(s).

VICPAS supply 2711-M3A19L1 Touch Screen Monitor, membrane keypad switch, LCD display, HMI Case and gasket. All of them with VICPAS 180 days warranty and support Urgent Worldwide Shipping.
The user is able to control the 2711-M3A19L1 HMI using the Micro Keypad to input information and data. This 2711-M3A19L1 unit is powered using 24 Volts DC power and has 240 KB of memory. The most common 2711-M3A19L1 Series are A and B; the most common firmware include 4.00-4.48.

This 2711-M3A19L1 Panelview 300 micro has a DF1 screen lets you display and change the DF1/full duplex communication settings for a DF1 PV 300 micro terminal. Sets the communication parameters for the DF1 port on the PV 300 terminal. The settings need to match the target device. You can switch between the available combinations for parity, data bits, and stop bits. The DF1 port on the PLC-5 controllers allows a parity of none or even parity with 8 Data Bits.





Specifications:

The table below describes the parameters of the 2711-M3A19L1 PanelView 300 membrane keypad switch.

Part Number : 2711-M3A19L1
Product Line: PanelView 300
Screen diagonal 3 in
Warranty: 6 mouths Warranty
Input Power 24 VDC
Software: Panelbuilder 32
Mounting position: vertical
Design as touch screen: No
Keyboard fonts: US English
Firmware 4.00-4.48


Related PanelView 300 Series Part No. :

PanelView 300 Description Inventory status
2711-K3A10L1 PanelView 300 Membrane Keypad Switch In Stock
2711-K3A17L1 PanelView 300 Membrane Keyboard Keypad Available Now
2711-K3A2L1 Allen Bradley PanelView 300 Keypad Switch In Stock
2711-K3A5L1 PanelView 300 Membrane Keypad Keyboard Available Now
2711-K3A5L1K Allen Bradley Panel View 300 HMI Parts Repair In Stock
2711-M3A18L1 PanelView 300 Membrane Keyboard Keypad Available Now
2711-M3A19L1 Allen Bradley PanelView 300 Micro Operator Interface Parts Available Now
Panel View 300 Description Inventory status

FAQ:

Question:How many function keys are on the 2711-M3A19L1 membrane keypad?

Answer:The 2711-M3A19L1 PanelView 300 Terminal has 8 keypad function keys.


Question: WDoes the 2711-M3A19L1 PanelView 300 Terminal have a replacement backlight?

Answer:No, the 2711-M3A19L1 PanelView 300 Terminal's backlight is non-replaceable.


Question: What is the 2711-M3A19L1 PanelView 300 HMI parts price?

Answer: Submit a fast quote, send VICPAS an email for best price.



Common misspellings:

  • 2711M3A19L1
  • 27l1-M3A19L1
  • 271l-M3A19L1
  • 2711-M3Al9L1
  • 2711-M3A1911
  • 2711-M3A19Ll
