PanelView 5500 2715-T15CD Touch Screen Film Display

PanelView 5500 2715-T15CD Touch Screen Film Display

PanelView 5500 2715-T15CD Touch Screen Film Display
PanelView 5500 2715-T15CD Touch Screen Film DisplayPanelView 5500 2715-T15CD Touch Screen Film DisplayPanelView 5500 2715-T15CD Touch Screen Film DisplayPanelView 5500 2715-T15CD Touch Screen Film Display
CategoriesPanelView 5500
BrandVICPAS
Model2715-T15CD
Product LineAllen-Bradley PanelView 5500 Repair Kit
Size15 inches
BrandAllen-Bradley
Shipping2-3 workdays
PartsResistive Touch Panel, Front Film and LCD Display
FPC10 wires
Warranty365 Days
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, MoneyGram, T/T, Paypal, PayPal, Credit Card
Update TimeJul 22,2024
Detail Information

Allen-Bradley PanelView 5500 HMI 2715-T15CD Front Overlay Touch Digitizer Monitor Repair Replacement

Order each part separately is available

Allen-Bradley PanelView 5500 HMI 2715-T15CD Front Overlay Touchscreen Replacement

The PanelView 5500 HMI 2715-T15CD Touch Screen Glass LCD Display Protective Film terminal has a color display with a touch screen and navigation key, or a touch screen, navigation key, and keypad for operator control.

• Analog, resistive, touch screens provide accurate, durable touch with excellent reliability for control of industrial applications.

• Keypad models are similar except for the number of function keys to the left (L#) and right (R#) of the display. Larger models have more keys.


The PanelView Standard 2715-T15CD Touch Digitizer Monitor Front Overlay LCD Display terminals feature pixel graphics capabilities and functionality in color, grayscale, and monochrome displays. These rugged electronic operator interface solutions are available in a variety of sizes and configurations to meet specific application requirements. All use common development software to simplify programming and improve operator productivity.


The PanelView 5500 HMI 2715-T15CD LCD Display Protective Film Touch Panel Glass terminal communicates with PLC and SLC controllers over EtherNet/IP, DeviceNet, ControlNet, DH-485, DH+, and remote I/O networks, or by using serial communication.Other features supported by the PanelView Standard line include advanced alarm handling, screen security, analog gauges, ATA memory card, universal language support, and online printing for more intuitive operator control.


VICPAS supply Allen Bradley PanelView 5500 HMI 2715-T15CD Resistive Touch Panel, Front Overlay and LCD Display with 365 Days warranty and support Urgent Worldwide Shipping.






Specifications:

The table below describes the parameters of the 2715-T15CD PanelView 5500 Parts.

Part Number: 2715-T15CD
Display Size: 15 inches
Display Type: Color TFT LCD
Color Depth: 18-bit color graphics
Display Resolution: 1024 x 768 XGA, 4:3
Brightness: 300 cd/m2 (Nits)
Input Voltage: 24V DC nom (18…30V DC)
USB Host Ports: 0.5A at 5V DC
Status Indicators: STS (green), ERR (red)
Warranty: 365 Days


Related Allen Bradley PanelView 5500 Terminals Part No. :

PanelView 5500 Description Inventory status
2715-T15CA 2715-T15CA PanelView 5500 Glass Panel Overlay Repair In Stock
2715-T15CA-B 2715-T15CA-B PanelView 5500 15'' Overlay Touch Screen In Stock
2715-T15CD PanelView 5500 2715-T15CD Touch Screen Film Display In Stock
2715-T15CD-B PanelView 5500 15'' 2715-T15CD-B HMI Touch Panel Film Available Now
2715-B15CA PanelView 5500 2715-B15CA 15'' Keypad Screen Display Available Now
2715-B15CA-B PanelView 5500 2715-B15CA-B Switch Membrane Touch Kit In Stock
2715-B15CD 2715-B15CD PanelView 5500 Panel Glass Display Keyboard In Stock
2715-B15CD-B 2715-B15CD-B PanelView 5500 Keypad Membrane Touch Kit Available Now
2715-T19CA 2715-T19CA PanelView 5500 Protective Film Panel Repair Available Now
2715-T19CA-B PanelView 5500 2715-T19CA-B HMI Touch Overlay Display In Stock
2715-T19CD 2715-T19CD PanelView 5500 Overlay Touch Glass Repair In Stock
2715-T19CD-B 2715-T19CD-B 19'' PanelView 5500 Touch Film HMI Repair In Stock
PanelView 5500 HMI Description Inventory status

PanelView 5500 HMI Manuals PDF Download:

  • Allen-Bradley PanelView 5500 Terminals User Manual
  • Allen-Bradley PanelView Standard Terminal Specifications
  • PanelView 5500 Specifications Technical Data

  • FAQ:

    Question: What is the size of the 2715-T15CD Touch Digitizer Monitor, Front Overlay and LCD Display?

    Answer: The 2715-T15CD HMI Touch Panel, Protective Film and LCD Display are 15-inch.


    Question: What is the 2715-T15CD Panelview 5500 Resistive Touch Screen, Protective Film and LCD Screen Display HMI parts price?

    Answer: Submit a fast quote, send VICPAS an email for best price.


    Question: What do the two indicators on the back of the terminal do?

    Answer: The back of the 2715-T15CD Touch Screen Front Film LCD Display Hmi terminal has two indicators to identify system status:

  • • STS indicator (green) indicates that the 2715-T15CD Touch Digitizer Monitor Overlay LCD Display terminal is on and in use.
  • • ERR indicator (red) indicates hardware and firmware faults. At startup, the STS and ERR indicators blink on and off, then the STS indicator blinks to signal progress during startup. If the indicators remain off, check the power cable. After a successful startup, the STS indicator remains on.
  • What do the two indicators on the back of the terminal do?
